背景

Spring Authorization Server （以下简称?SAS）是 Spring 团队最新开发适配 OAuth 协议的授权服务器项目，旨在替代原有的 Spring Security OAuth Server。
经过半年的开发和孵化，目前已经发布了 0.2.0 版本，已支持授权码、客户端、刷新、注销等 OAuth 协议。
目前 SAS 项目已经迁移至官方正式仓库维护，成为官方的正式子项目。
本文环境基于 Spring Boot 2.5.3 && SAS 0.2.0

开始上手

1. 核心依赖

这里需要 SAS 、Security, 注意看注释

Spring官宣新家族成员：Spring Authorization Server

2. 配置 security 安全认证

定义用户来源及其 form 认证的信息

Spring官宣新家族成员：Spring Authorization Server

3. 配置 SAS 服务器

@Configuration
@EnableWebSecurity
public class AuthServerConfiguration {

  // security 挂载 SAS 【最重要的一步】
 @Bean
 @Order(Ordered.HIGHEST_PRECEDENCE)
 public SecurityFilterChain authorizationServerSecurityFilterChain(HttpSecurity http) throws Exception {
  OAuth2AuthorizationServerConfiguration.applyDefaultSecurity(http);
  return http.formLogin(Customizer.withDefaults()).build();
 }

  // 客户端来源
  @Bean
  public RegisteredClientRepository registeredClientRepository() {
      RegisteredClient client = RegisteredClient.withId("pig")
              .clientId("pig")
              .clientSecret("{noop}pig")
              .clientAuthenticationMethod(ClientAuthenticationMethod.CLIENT_SECRET_BASIC)
              .authorizationGrantTypes(authorizationGrantTypes -> {
                  authorizationGrantTypes.add(AuthorizationGrantType.AUTHORIZATION_CODE);
                  authorizationGrantTypes.add(AuthorizationGrantType.REFRESH_TOKEN);
              })
              .redirectUri("https://pig4cloud.com")
              .build();
      return new InMemoryRegisteredClientRepository(client);
  }

  // 以下两个bean 定义 生成jwt 的配置，可以直接参考文末源码介绍，这里就不在截图
 @Bean
 @SneakyThrows
 public JWKSource<SecurityContext> jwkSource() {
    ....
  }

  @Bean
  public static JwtDecoder jwtDecoder(JWKSource<SecurityContext> jwkSource) {
   ...
  }
}

测试运行

通过以上配置即可搭建完成 SAS 服务端，我们以授权码模式测试

浏览器访问如下链接，会重定向至登录页

Spring官宣新家族成员：Spring Authorization Server

输入账号密码后，会携带 code 自动回调至目标页面

Spring官宣新家族成员：Spring Authorization Server

使用 code 换 token

 curl --location --request POST 'http://localhost:3000/oauth2/token' \
> --header 'Authorization: Basic cGlnOnBpZw==' \
> --header 'Content-Type: application/x-www-form-urlencoded' \
> --data-urlencode 'grant_type=authorization_code' \
> --data-urlencode 'code=dn0GmDB-4hAfg-Kc9luUkuqZn4keJF9ZkUTlmcSRnYn8uzfEV9Ih429MH-9O77TPEVqPxXAJLPgxq-znOpiI-28Sek305db8Rezd46ods95FrjCSMq_HAswCtAJV4Vrt' \
> --data-urlencode 'redirect_uri=https://pig4cloud.com'
{"access_token":"eyJraWQiOiI2YmU4YzhlYi0wNDA2LTQxZGMtOGE2ZS0xOWZmNThlYzY4MTIiLCJhbGciOiJSUzI1NiJ9.eyJzdWIiOiJsZW5nbGVuZyIsImF1ZCI6InBpZyIsIm5iZiI6MTYyOTM2OTcwMSwiZXhwIjoxNjI5MzcwMDAxLCJpYXQiOjE2MjkzNjk3MDF9.Vb_1kGTqRTejBN8aPRFZPs_3cAa7jFC7XPuG4pPptpTtVbso0iHE5ghuNfFAk3DO4vDBjokYSWwNBfj9RuiwI5ElWbbK71leE8BAGpQa35pKYoKgXybf92KWbNIxHI3BXuQww8iWtQI5_xgNUWVJ6sx0uI4f5hA_vGZEM0vHza0FZZWPAFt9X6j_R0tmu0JPnnnQ2sTQyFJUzQomqbF1OpZaJi3_HjnjX7g_Z-NdJi-1s9jItNtzaaYzkyXnhmKLQoEq-OVxOOL0C2hP_bAZ1dy39HDUHuosxtGPsw49wWuqZQTcMbr9YojbyUMkR7k30zAAByjUmkXzjaS4T-EIaA","refresh_token":"YlxCAnSyvtq1HcKqE3D3o-P_lT90wxdRQ6jfWbwQoKQaeFUZr51gQQQawSfpUUH4yf9kW51v7ENH2o4pDot7yIeN2tljVpKU6zuolj6gFKq0uDA6KkDDz54cDzfx1aw4","token_type":"Bearer","expires_in":"299"}

刷新 token

curl --location --request POST 'http://localhost:3000/oauth2/token' \
> --header 'Authorization: Basic cGlnOnBpZw==' \
> --header 'Content-Type: application/x-www-form-urlencoded' \
> --data-urlencode 'grant_type=authorization_code' \
> --data-urlencode 'code=dn0GmDB-4hAfg-Kc9luUkuqZn4keJF9ZkUTlmcSRnYn8uzfEV9Ih429MH-9O77TPEVqPxXAJLPgxq-znOpiI-28Sek305db8Rezd46ods95FrjCSMq_HAswCtAJV4Vrt' \
> --data-urlencode 'redirect_uri=https://pig4cloud.com'
{"access_token":"eyJraWQiOiI2YmU4YzhlYi0wNDA2LTQxZGMtOGE2ZS0xOWZmNThlYzY4MTIiLCJhbGciOiJSUzI1NiJ9.eyJzdWIiOiJsZW5nbGVuZyIsImF1ZCI6InBpZyIsIm5iZiI6MTYyOTM2OTcwMSwiZXhwIjoxNjI5MzcwMDAxLCJpYXQiOjE2MjkzNjk3MDF9.Vb_1kGTqRTejBN8aPRFZPs_3cAa7jFC7XPuG4pPptpTtVbso0iHE5ghuNfFAk3DO4vDBjokYSWwNBfj9RuiwI5ElWbbK71leE8BAGpQa35pKYoKgXybf92KWbNIxHI3BXuQww8iWtQI5_xgNUWVJ6sx0uI4f5hA_vGZEM0vHza0FZZWPAFt9X6j_R0tmu0JPnnnQ2sTQyFJUzQomqbF1OpZaJi3_HjnjX7g_Z-NdJi-1s9jItNtzaaYzkyXnhmKLQoEq-OVxOOL0C2hP_bAZ1dy39HDUHuosxtGPsw49wWuqZQTcMbr9YojbyUMkR7k30zAAByjUmkXzjaS4T-EIaA","refresh_token":"YlxCAnSyvtq1HcKqE3D3o-P_lT90wxdRQ6jfWbwQoKQaeFUZr51gQQQawSfpUUH4yf9kW51v7ENH2o4pDot7yIeN2tljVpKU6zuolj6gFKq0uDA6KkDDz54cDzfx1aw4","token_type":"Bearer","expires_in":"299"}%     lengleng@MacBook-Pro  ~/Downloads/auth-server-demo   password ± 
 lengleng@MacBook-Pro  ~/Downloads/auth-server-demo   password ±  curl --location --request POST 'http://localhost:3000/oauth2/token' \
> --header 'Authorization: Basic cGlnOnBpZw==' \
> --header 'Content-Type: application/x-www-form-urlencoded' \
> --data-urlencode 'grant_type=refresh_token' \
> --data-urlencode 'refresh_token=YlxCAnSyvtq1HcKqE3D3o-P_lT90wxdRQ6jfWbwQoKQaeFUZr51gQQQawSfpUUH4yf9kW51v7ENH2o4pDot7yIeN2tljVpKU6zuolj6gFKq0uDA6KkDDz54cDzfx1aw4' \
>
{"access_token":"eyJraWQiOiI2YmU4YzhlYi0wNDA2LTQxZGMtOGE2ZS0xOWZmNThlYzY4MTIiLCJhbGciOiJSUzI1NiJ9.eyJzdWIiOiJsZW5nbGVuZyIsImF1ZCI6InBpZyIsIm5iZiI6MTYyOTM2OTc2OSwiZXhwIjoxNjI5MzcwMDY5LCJpYXQiOjE2MjkzNjk3Njl9.dj_ktchQnTKRXGSQK7EZ3FAdz8StPOo27rURdCI8FN6jM3RFRD0s67v4LB1SRexl5KKHPuH6yYHhlr_u0um8ZpeQIrkumA2COukJAzy5O3SLsBYvLqipz-Ea9h9RZvC7EQZG-AbVJ378X214WxdsOYj1UPTv4Iegy4QsgERJSijINrCQZc0msHqSWIc_p61o2KIc8qaekrkZgY_JqCOz8K7x6drKvJ5gyWc9CyzeOrob5WrJfQGqqhjwjTl76g-9YyZ5Q97LX5lKRh8HOU6AUgKCyd4Jdol6PR6CkYd3gd4kyd5Ra7c3GbhzGUaxDrez79NDPx0aRAB9GA9mSohtsw","refresh_token":"YlxCAnSyvtq1HcKqE3D3o-P_lT90wxdRQ6jfWbwQoKQaeFUZr51gQQQawSfpUUH4yf9kW51v7ENH2o4pDot7yIeN2tljVpKU6zuolj6gFKq0uDA6KkDDz54cDzfx1aw4","token_type":"Bearer","expires_in":"299"}%

撤销令牌

通过 access_token

curl --location --request POST 'http://localhost:3000/oauth2/revoke' \
--header 'Authorization: Basic cGlnOnBpZw==' \
--header 'Content-Type: application/x-www-form-urlencoded' \
--data-urlencode 'token=eyJraWQiOiI0NmM3Zjk0OS01NmZmLTRlMjgtYmI4Zi0wNjZjYWU4ODllNDkiLCJhbGciOiJSUzI1NiJ9.eyJzdWIiOiJsZW5nbGVuZyIsImF1ZCI6InBpZyIsIm5iZiI6MTYyOTM0MzM4NiwiZXhwIjoxNjI5MzQzNjg2LCJpYXQiOjE2MjkzNDMzODZ9.avRZ9NuybP8bqenEstvDq3SAKuSI6Y3ihh2PqeiQvwkUAWBPY6N9JCaxJllKhrcS6OgL76I38Yvt0B1ICMFistqemWl1rxQUB2aXpZuTwnPjxtxV6deDxyr--Y1w7I9jVpT5jnaqOXDIZ6dhIlUCfqBPT9a4DmwuEsz5H60KUO-NbMM66DPDxvTgauuylhrjiPQgaDyaxFHbtdw6qq_pgFI023fkIASodauCFiUcl64HKV3or9B3OkXW0EgnA553ofTbgz0hlROMfee15wuzOAXTUkhlUOjjosuEslimT9vFM9wtRza4o864Gi_j_zIhIoSSmRfUScXTgt9aZT1xlQ' \
--data-urlencode 'token_type_hint=access_token'

通过 refresh_token

curl --location --request POST 'http://localhost:3000/oauth2/revoke' \
--header 'Authorization: Basic cGlnOnBpZw==' \
--header 'Content-Type: application/x-www-form-urlencoded' \
--data-urlencode 'token=ku4R4n7YD1f584KXj4k_3GP9o-HbdY-PDIIh-twPVJTmvHa5mLIoifaNhbBvFNBbse6_wAMcRoOWuVs9qeBWpxQ5zIFrF1A4g1Q7LhVAfH1vo9Uc7WL3SP3u82j0XU5x' \
--data-urlencode 'token_type_hint=refresh_token'
