一：简述
本文通过分析mybatis的源码来展示mybatis是如何帮我们实现一个查询的方法的。

二：时序图

三：源码分析

        UserMapper mapper = sqlSession.getMapper(UserMapper.class);

注：这里获取的是一个代理对象，而我们一般从Spring容器中获取的也是同样的代理对象，只不过是交给Spring管理了而已

1.获取代理类Mapper

sqlSession的getMapper()方法会先调用configuration的getMapper()方法，最后调用mapperRegistry.getMapper()

public <T> T getMapper(Class<T> type) {
    //最后会去调用MapperRegistry.getMapper
    return configuration.<T>getMapper(type, this);
  }

public <T> T getMapper(Class<T> type, SqlSession sqlSession) {
    return mapperRegistry.getMapper(type, sqlSession);
  }

在我们解析配置的时候，会将解析好的Mapper接口和对应的代理工厂关联起来，保存在mapperRegistry的knownMappers中。而mapperRegistry的getMapper方法就是从这个knownMappers的map中获取工厂对象，然后利用工厂创建代理类并且返回。

public <T> T getMapper(Class<T> type, SqlSession sqlSession) {
    //knownMapper是一个map key是Mapper接口的类对象，
    //value是对应的代理工厂 用来创建代理对象的
    final MapperProxyFactory<T> mapperProxyFactory = (MapperProxyFactory<T>) knownMappers.get(type);
    if (mapperProxyFactory == null) {
      throw new BindingException("Type " + type + " is not known to the MapperRegistry.");
    }
    try {
      return mapperProxyFactory.newInstance(sqlSession);
    } catch (Exception e) {
      throw new BindingException("Error getting mapper instance. Cause: " + e, e);
    }
  }

代理工厂创建代理类：

public T newInstance(SqlSession sqlSession) {
    final MapperProxy<T> mapperProxy = new MapperProxy<T>(sqlSession, mapperInterface, methodCache);
    return newInstance(mapperProxy);
  }

protected T newInstance(MapperProxy<T> mapperProxy) {
    //用JDK自带的动态代理生成映射器
    return (T) Proxy.newProxyInstance(mapperInterface.getClassLoader(), new Class[] { mapperInterface }, mapperProxy);
  }

所以返回的对象应该是一个MapperProxy对象，而我们在调用mapper的方法的时候应该也是进入到MapperProxy的invoke()方法。

2.执行查询方法
根据上面的分析，我们会调用MapperProxy的invoke()方法

public Object invoke(Object proxy, Method method, Object[] args) throws Throwable {
    //代理以后，所有Mapper的方法调用时，都会调用这个invoke方法
    //并不是任何一个方法都需要执行调用代理对象进行执行，如果这个方法是Object中通用的方法（toString、hashCode等）无需执行
    if (Object.class.equals(method.getDeclaringClass())) {
      try {
        return method.invoke(this, args);
      } catch (Throwable t) {
        throw ExceptionUtil.unwrapThrowable(t);
      }
    }
    //获取MapperMethod MapperMethod会执行代理的一些逻辑
    final MapperMethod mapperMethod = cachedMapperMethod(method);
    //执行
    return mapperMethod.execute(sqlSession, args);
  }

public Object execute(SqlSession sqlSession, Object[] args) {
    Object result;
    //可以看到执行时就是4种情况，insert|update|delete|select，
    //分别调用SqlSession的4大类方法 我们这里就以查询为例
    //查询是最复杂的 因为还需要对结果集进行处理
    if (SqlCommandType.INSERT == command.getType()) {
      Object param = method.convertArgsToSqlCommandParam(args);
      result = rowCountResult(sqlSession.insert(command.getName(), param));
    } else if (SqlCommandType.UPDATE == command.getType()) {
      Object param = method.convertArgsToSqlCommandParam(args);
      result = rowCountResult(sqlSession.update(command.getName(), param));
    } else if (SqlCommandType.DELETE == command.getType()) {
      Object param = method.convertArgsToSqlCommandParam(args);
      result = rowCountResult(sqlSession.delete(command.getName(), param));
    } else if (SqlCommandType.SELECT == command.getType()) {
      if (method.returnsVoid() && method.hasResultHandler()) {
        //如果有结果处理器
        executeWithResultHandler(sqlSession, args);
        result = null;
      } else if (method.returnsMany()) {
        //如果结果有多条记录
        result = executeForMany(sqlSession, args);
      } else if (method.returnsMap()) {
        //如果结果是map
        result = executeForMap(sqlSession, args);
      } else {
        //否则就是一条记录
        Object param = method.convertArgsToSqlCommandParam(args);
        result = sqlSession.selectOne(command.getName(), param);
      }
    } else {
      throw new BindingException("Unknown execution method for: " + command.getName());
    }
    if (result == null && method.getReturnType().isPrimitive() && !method.returnsVoid()) {
      throw new BindingException("Mapper method '" + command.getName()
          + " attempted to return null from a method with a primitive return type (" + method.getReturnType() + ").");
    }
    return result;
  }

我们接下来分析如果只有一条记录的情况，首先会调用
convertArgsToSqlCommandParam()方法对参数进行处理
这里就是把参数转化为一个map存起来，其中key代表的是参数的名称 value是参数的值

public Object convertArgsToSqlCommandParam(Object[] args) {
      final int paramCount = params.size();
      if (args == null || paramCount == 0) {
        //如果没参数
        return null;
      } else if (!hasNamedParameters && paramCount == 1) {
        //如果只有一个参数
        return args[params.keySet().iterator().next().intValue()];
      } else {
        //否则，返回一个ParamMap，修改参数名，参数名就是其位置
        final Map<String, Object> param = new ParamMap<Object>();
        int i = 0;
        for (Map.Entry<Integer, String> entry : params.entrySet()) {
          //1.先加一个#{0},#{1},#{2}...参数
          param.put(entry.getValue(), args[entry.getKey().intValue()]);
          // issue #71, add param names as param1, param2...but ensure backward compatibility
          final String genericParamName = "param" + String.valueOf(i + 1);
          if (!param.containsKey(genericParamName)) {
            //2.再加一个#{param1},#{param2}...参数
            //你可以传递多个参数给一个映射器方法。
            //默认情况下它们将会以它们在参数列表中的位置来命名,比如:#{param1},#{param2}等。
            //如果你想改变参数的名称(只在多参数情况下) ,那么你可以在参数上使用@Param(“paramName”)注解。
            param.put(genericParamName, args[entry.getKey()]);
          }
          i++;
        }
        return param;
      }
    }

然后调用sqlSession的selectOne()方法，进入到DefaultSqlSession的selectOne()方法，然后调用selectList()方法。

public <T> T selectOne(String statement, Object parameter) {
    // Popular vote was to return null on 0 results and throw exception on too many.
    //转而去调用selectList,很简单的，如果得到0条则返回null，得到1条则返回1条，得到多条报TooManyResultsException错
    List<T> list = this.<T>selectList(statement, parameter);
    if (list.size() == 1) {
      return list.get(0);
    } else if (list.size() > 1) {
      throw new TooManyResultsException("Expected one result (or null) to be returned by selectOne(), but found: " + list.size());
    } else {
      return null;
    }
  }

public <E> List<E> selectList(String statement, Object parameter, RowBounds rowBounds) {
    try {
      //根据statement id找到对应的MappedStatement
      MappedStatement ms = configuration.getMappedStatement(statement);
      //转而用执行器来查询结果,注意这里传入的ResultHandler是null
      return executor.query(ms, wrapCollection(parameter), rowBounds, Executor.NO_RESULT_HANDLER);
    } catch (Exception e) {
      throw ExceptionFactory.wrapException("Error querying database.  Cause: " + e, e);
    } finally {
      ErrorContext.instance().reset();
    }
  }

进一步调用executor.query(),而这里如果我们开启了二级缓存，那么会先进入到CachingExecutor，这一块很简单，缓存中有就从缓存中拿，没有就继续调用BaseExecutor中的query方法

public <E> List<E> query(MappedStatement ms, Object parameterObject, RowBounds rowBounds, ResultHandler resultHandler) throws SQLException {
    BoundSql boundSql = ms.getBoundSql(parameterObject);
	//query时传入一个cachekey参数
    CacheKey key = createCacheKey(ms, parameterObject, rowBounds, boundSql);
    return query(ms, parameterObject, rowBounds, resultHandler, key, boundSql);
  }

public <E> List<E> query(MappedStatement ms, Object parameterObject, RowBounds rowBounds, ResultHandler resultHandler, CacheKey key, BoundSql boundSql)
      throws SQLException {
    Cache cache = ms.getCache();
    //默认情况下是没有开启缓存的(二级缓存).要开启二级缓存,你需要在你的 SQL 映射文件中添加一行: <cache/>
    //简单的说，就是先查CacheKey，查不到再委托给实际的执行器去查
    if (cache != null) {
      flushCacheIfRequired(ms);
      if (ms.isUseCache() && resultHandler == null) {
        ensureNoOutParams(ms, parameterObject, boundSql);
        @SuppressWarnings("unchecked")
        List<E> list = (List<E>) tcm.getObject(cache, key);
        if (list == null) {
          list = delegate.<E> query(ms, parameterObject, rowBounds, resultHandler, key, boundSql);
          tcm.putObject(cache, key, list); // issue #578 and #116
        }
        return list;
      }
    }
    return delegate.<E> query(ms, parameterObject, rowBounds, resultHandler, key, boundSql);
  }

这里是先从localCache中查，也就是mybatis的一级缓存中查询
如果有就返回，没有再执行queryFromDatabase()方法 从数据库中查，默认以及缓存是打开的，我们可以设置一级缓存失效:
将缓存的作用域设置为STATEMENT

public <E> List<E> query(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, CacheKey key, BoundSql boundSql) throws SQLException {
    ErrorContext.instance().resource(ms.getResource()).activity("executing a query").object(ms.getId());
    //如果已经关闭，报错
    if (closed) {
      throw new ExecutorException("Executor was closed.");
    }
    //先清局部缓存，再查询.但仅查询堆栈为0，才清。为了处理递归调用
    if (queryStack == 0 && ms.isFlushCacheRequired()) {
      clearLocalCache();
    }
    List<E> list;
    try {
      //加一,这样递归调用到上面的时候就不会再清局部缓存了
      queryStack++;
      //先根据cachekey从localCache去查
      list = resultHandler == null ? (List<E>) localCache.getObject(key) : null;
      if (list != null) {
        //若查到localCache缓存，处理localOutputParameterCache
        handleLocallyCachedOutputParameters(ms, key, parameter, boundSql);
      } else {
        //从数据库查
        list = queryFromDatabase(ms, parameter, rowBounds, resultHandler, key, boundSql);
      }
    } finally {
      //清空堆栈
      queryStack--;
    }
    if (queryStack == 0) {
      //延迟加载队列中所有元素
      for (DeferredLoad deferredLoad : deferredLoads) {
        deferredLoad.load();
      }
      // issue #601
      //清空延迟加载队列
      deferredLoads.clear();
      if (configuration.getLocalCacheScope() == LocalCacheScope.STATEMENT) {
        // issue #482
    	//如果是STATEMENT，清本地缓存
        clearLocalCache();
      }
    }
    return list;
  }

//从数据库查
  private <E> List<E> queryFromDatabase(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, CacheKey key, BoundSql boundSql) throws SQLException {
    List<E> list;

    localCache.putObject(key, EXECUTION_PLACEHOLDER);
    try {
    //真正去查询
      list = doQuery(ms, parameter, rowBounds, resultHandler, boundSql);
    } finally {
      //最后删除占位符
      localCache.removeObject(key);
    }
    //加入缓存
    localCache.putObject(key, list);
    //如果是存储过程，OUT参数也加入缓存
    if (ms.getStatementType() == StatementType.CALLABLE) {
      localOutputParameterCache.putObject(key, parameter);
    }
    return list;
  }

真正去查询数据库则是调用doQuery()方法，而doQuery()方法则是去调用我们设置的执行器的doQuery()方法，默认是使用SimpleExecutor，所以我们进入到SimpleExecutor的doQuery()方法。

public <E> List<E> doQuery(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, BoundSql boundSql) throws SQLException {
    Statement stmt = null;
    try {
      Configuration configuration = ms.getConfiguration();
      //新建一个StatementHandler
      //这里看到ResultHandler传入了 并且在configuration的newnewStatementHandler方法还做了插件的包装，（由于篇幅这里就不多说了，可以去看我的前一篇文章有关插件的）
      StatementHandler handler = configuration.newStatementHandler(wrapper, ms, parameter, rowBounds, resultHandler, boundSql);
      //准备语句
      stmt = prepareStatement(handler, ms.getStatementLog());
      //StatementHandler.query
      return handler.<E>query(stmt, resultHandler);
    } finally {
      closeStatement(stmt);
    }
  }

public StatementHandler newStatementHandler(Executor executor, MappedStatement mappedStatement, Object parameterObject, RowBounds rowBounds, ResultHandler resultHandler, BoundSql boundSql) {
    //创建路由选择语句处理器
    //RoutingStatementHandler这里使用的是一个委派模式 根据配置路由到不同的StatementHandler
    //而默认的StatementHandler是PreparedStatementHandler
    StatementHandler statementHandler = new RoutingStatementHandler(executor, mappedStatement, parameterObject, rowBounds, resultHandler, boundSql);
    //插件在这里插入
    statementHandler = (StatementHandler) interceptorChain.pluginAll(statementHandler);
    return statementHandler;
  }

我们接着分析prepareStatement方法，这里是获取一个Statement对象用于执行sql语句

private Statement prepareStatement(StatementHandler handler, Log statementLog) throws SQLException {
    Statement stmt;
    //获取一个数据库连接
    Connection connection = getConnection(statementLog);
    //调用StatementHandler.prepare
    stmt = handler.prepare(connection);
    //调用StatementHandler.parameterize
    handler.parameterize(stmt);
    return stmt;
  }

handler.prepare(connection)这个方法就是获取Statement对象的，进入到方法中，会先到BaseStatementHandler的prepare方法

public Statement prepare(Connection connection) throws SQLException {
    ErrorContext.instance().sql(boundSql.getSql());
    Statement statement = null;
    try {
      //实例化Statement 默认是PreparedStatement
      statement = instantiateStatement(connection);
      //设置超时
      setStatementTimeout(statement);
      //设置读取条数
      setFetchSize(statement);
      return statement;
    } catch (SQLException e) {
      closeStatement(statement);
      throw e;
    } catch (Exception e) {
      closeStatement(statement);
      throw new ExecutorException("Error preparing statement.  Cause: " + e, e);
    }
  }

instantiateStatement方法是用来实例化Statement的，默认是预编译的Statement，也就是PreparedStatement，然后调用connection.prepareStatement()

protected Statement instantiateStatement(Connection connection) throws SQLException {
    //调用Connection.prepareStatement
    String sql = boundSql.getSql();
    if (mappedStatement.getKeyGenerator() instanceof Jdbc3KeyGenerator) {
      String[] keyColumnNames = mappedStatement.getKeyColumns();
      if (keyColumnNames == null) {
        return connection.prepareStatement(sql, PreparedStatement.RETURN_GENERATED_KEYS);
      } else {
        return connection.prepareStatement(sql, keyColumnNames);
      }
    } else if (mappedStatement.getResultSetType() != null) {
      return connection.prepareStatement(sql, mappedStatement.getResultSetType().getValue(), ResultSet.CONCUR_READ_ONLY);
    } else {
      return connection.prepareStatement(sql);
    }
  }

然后我们接着分析handler.parameterize(stmt);这个方法是对参数进行处理的，会调用到DefaultParameterHandler的setParameters进行处理，包括typeHandler对参数的处理

public void setParameters(PreparedStatement ps) throws SQLException {
    ErrorContext.instance().activity("setting parameters").object(mappedStatement.getParameterMap().getId());
    List<ParameterMapping> parameterMappings = boundSql.getParameterMappings();
    if (parameterMappings != null) {
      //循环设参数
      for (int i = 0; i < parameterMappings.size(); i++) {
        ParameterMapping parameterMapping = parameterMappings.get(i);
        if (parameterMapping.getMode() != ParameterMode.OUT) {
          //如果不是OUT，才设进去
          Object value;
          String propertyName = parameterMapping.getProperty();
          if (boundSql.hasAdditionalParameter(propertyName)) { // issue #448 ask first for additional params
            //若有额外的参数, 设为额外的参数
            value = boundSql.getAdditionalParameter(propertyName);
          } else if (parameterObject == null) {
            //若参数为null，直接设null
            value = null;
          } else if (typeHandlerRegistry.hasTypeHandler(parameterObject.getClass())) {
            //若参数有相应的TypeHandler，直接设object
            value = parameterObject;
          } else {
            //除此以外，MetaObject.getValue反射取得值设进去
            MetaObject metaObject = configuration.newMetaObject(parameterObject);
            value = metaObject.getValue(propertyName);
          }
          TypeHandler typeHandler = parameterMapping.getTypeHandler();
          JdbcType jdbcType = parameterMapping.getJdbcType();
          if (value == null && jdbcType == null) {
            //不同类型的set方法不同，所以委派给子类的setParameter方法
            jdbcType = configuration.getJdbcTypeForNull();
          }
          typeHandler.setParameter(ps, i + 1, value, jdbcType);
        }
      }
    }
  }

当Statement和参数都已经设置完成了之后，根据jdbc的流程，应该是要执行sql语句并且获取结果集了

  public <E> List<E> doQuery(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, BoundSql boundSql) throws SQLException {
    Statement stmt = null;
    try {
      Configuration configuration = ms.getConfiguration();
      //新建一个StatementHandler
      //这里看到ResultHandler传入了
      StatementHandler handler = configuration.newStatementHandler(wrapper, ms, parameter, rowBounds, resultHandler, boundSql);
      //准备语句
      stmt = prepareStatement(handler, ms.getStatementLog());
      //StatementHandler.query 执行sql 以及处理结果集
      return handler.<E>query(stmt, resultHandler);
    } finally {
      closeStatement(stmt);
    }
  }

public <E> List<E> query(Statement statement, ResultHandler resultHandler) throws SQLException {
    PreparedStatement ps = (PreparedStatement) statement;
    //执行sql
    ps.execute();
    //处理结果集
    return resultSetHandler.<E> handleResultSets(ps);
  }

3.处理结果集
调用DefaultResultSetHandlerhandleResultSets()

@Override
  public List<Object> handleResultSets(Statement stmt) throws SQLException {
    ErrorContext.instance().activity("handling results").object(mappedStatement.getId());

    final List<Object> multipleResults = new ArrayList<Object>();

    int resultSetCount = 0;
    //获取包装的resultSet
    ResultSetWrapper rsw = getFirstResultSet(stmt);

    //获取resultMap
    List<ResultMap> resultMaps = mappedStatement.getResultMaps();
    //一个MappedStatement应该只有一个resultMap吧 为什么用List 不懂
    int resultMapCount = resultMaps.size();
    //检验配置的resultMap的数量
    validateResultMapsCount(rsw, resultMapCount);
    while (rsw != null && resultMapCount > resultSetCount) {
      ResultMap resultMap = resultMaps.get(resultSetCount);
      //处理结果集
      handleResultSet(rsw, resultMap, multipleResults, null);
      rsw = getNextResultSet(stmt);
      cleanUpAfterHandlingResultSet();
      resultSetCount++;
    }

    String[] resultSets = mappedStatement.getResulSets();
    if (resultSets != null) {
      while (rsw != null && resultSetCount < resultSets.length) {
        ResultMapping parentMapping = nextResultMaps.get(resultSets[resultSetCount]);
        if (parentMapping != null) {
          String nestedResultMapId = parentMapping.getNestedResultMapId();
          ResultMap resultMap = configuration.getResultMap(nestedResultMapId);
          handleResultSet(rsw, resultMap, null, parentMapping);
        }
        rsw = getNextResultSet(stmt);
        cleanUpAfterHandlingResultSet();
        resultSetCount++;
      }
    }

    return collapseSingleResultList(multipleResults);
  }

四：总结
本文分析了mybatis执行查询方法的主要流程，其他的增删改其实也是大同小异，甚至更简单，因为不需要对结果集进行处理，只需要返回一个int或者boolean就行了，有兴趣的同学可以去看下增删改的源码，加深一下理解。
