Description

The HTML5 <canvas> tag is used to draw graphics, on the fly, via scripting (usually JavaScript).

However, the <canvas> element has no drawing abilities of its own (it is only a container for graphics) - you must use a script to actually draw the graphics.

The getContext() method returns an object that provides methods and properties for drawing on the canvas.

This reference will cover the properties and methods of the getContext(“2d”) object, which can be used to draw text, lines, boxes, circles, and more - on the canvas.

Browser Support

Internet Explorer 9, Firefox, Opera, Chrome, and Safari support <canvas> and its properties and methods.

Note: Internet Explorer 8 and earlier versions, do not support the <canvas> element.

Colors, Styles, and Shadows

Property

fillStyle

Sets or returns the color, gradient, or pattern used to fill the drawing

gradient
英 [?ɡre?di?nt] 美 [?ɡre?di?nt]
n. (尤指公路或铁路的)坡度，斜率，倾斜度; (温度、压力等的)变化率，梯度变化曲线

Definition and Usage

The fillStyle property sets or returns the color, gradient, or pattern used to fill the drawing.

Property Values

Example

1 Define a red fill-color for the rectangle

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.fillStyle="#FF0000";
ctx.fillRect(20,20,150,100);

2 Define a gradient (top to bottom) as the fill style for the rectangle

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
var my_gradient=ctx.createLinearGradient(0,0,0,170);
my_gradient.addColorStop(0,"black");
my_gradient.addColorStop(1,"white");
ctx.fillStyle=my_gradient;
ctx.fillRect(20,20,150,100);

3 Define a gradient (left to right) as the fill style for the rectangle

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
var my_gradient=ctx.createLinearGradient(0,0,170,0);
my_gradient.addColorStop(0,"black");
my_gradient.addColorStop(1,"white");
ctx.fillStyle=my_gradient;
ctx.fillRect(20,20,150,100);

4 Define a gradient that goes from black, to red, to white, as the fill style for the rectangle

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
var my_gradient=ctx.createLinearGradient(0,0,170,0);
my_gradient.addColorStop(0,"black");
my_gradient.addColorStop(0.5,"red");
my_gradient.addColorStop(1,"white");
ctx.fillStyle=my_gradient;
ctx.fillRect(20,20,150,100);

5 Use an image to fill the drawing

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
var img=document.getElementById("lamp");
var pat=ctx.createPattern(img,"repeat");
ctx.rect(0,0,150,100);
ctx.fillStyle=pat;
ctx.fill();

strokeStyle

Sets or returns the color, gradient, or pattern used for strokes

stroke
英 [str??k] 美 [stro?k]
n. (打、击等的)一下;击球(动作);一击;划水动作;划桨动作
vt. 轻抚(动物的毛皮);抚摩(物体表面或头发等);轻挪;轻触;轻拭

Definition and Usage

The strokeStyle property sets or returns the color, gradient, or pattern used for strokes.

Property Values

Example

1 Use a stroke color of red to draw a rectangle.

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.strokeStyle="#FF0000";
ctx.strokeRect(20,20,150,100);

2 Use a gradient stroke to draw a rectangle.

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");

var gradient=ctx.createLinearGradient(0,0,170,0);
gradient.addColorStop("0","magenta");
gradient.addColorStop("0.5","blue");
gradient.addColorStop("1.0","red");

// Fill with gradient
ctx.strokeStyle=gradient;
ctx.lineWidth=5;
ctx.strokeRect(20,20,150,100);

3 Write the text “Big smile!” with a gradient stroke

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");

ctx.font="30px Verdana";
// Create gradient
var gradient=ctx.createLinearGradient(0,0,c.width,0);
gradient.addColorStop("0","magenta");
gradient.addColorStop("0.5","blue");
gradient.addColorStop("1.0","red");
// Fill with gradient
ctx.strokeStyle=gradient;
ctx.strokeText("Big smile!",10,50);

shadowColor

Sets or returns the color to use for shadows

Definition and Usage

The shadowColor property sets or returns the color to use for shadows.

Note: Use the shadowColor property together with the shadowBlur property to create a shadow.

Tip: Adjust the shadow by using the shadowOffsetX and shadowOffsetY properties.

Property Values

Example

1 Draw a red rectangle with a black shadow

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.shadowBlur=20;
ctx.shadowColor="black";
ctx.fillStyle="red";
ctx.fillRect(20,20,100,80);

shadowBlur

Sets or returns the blur level for shadows

Definition and Usage

The shadowBlur property sets or returns the blur level for shadows.

Property Values

Example

1 Draw a red rectangle with a black shadow, with blur level of 20

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.shadowBlur=20;
ctx.shadowColor="black";
ctx.fillStyle="red";
ctx.fillRect(20,20,100,80);

shadowOffsetX

Sets or returns the horizontal distance of the shadow from the shape

Definition and Usage

The shadowOffsetX property sets or returns the horizontal distance of the shadow from the shape.

• shadowOffsetX=0 indicates that the shadow is right behind the shape.
• shadowOffsetX=20 indicates that the shadow starts 20 pixels to the right (from the shape’s left position).
• shadowOffsetX=-20 indicates that the shadow starts 20 pixels to the left (from the shape’s left position).

Tip: To adjust the vertical distance of the shadow from the shape, use the shadowOffsetY property.

Property Values

Example

1 Draw a rectangle with a shadow placed 20/100 pixels to the right (from the rectangle’s left position)

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.shadowBlur=10;
ctx.shadowOffsetX=20;
ctx.shadowColor="black";
ctx.fillStyle="red";
ctx.fillRect(20,20,100,80);

var c = document.getElementById("myCanvas");
var ctx = c.getContext("2d");
ctx.shadowBlur = 10;
ctx.shadowOffsetX = 100;
ctx.shadowColor = "black";
ctx.fillStyle= "red";
ctx.fillRect(20, 20, 100, 80);

shadowOffsetY

Sets or returns the vertical distance of the shadow from the shape

Definition and Usage

The shadowOffsetY property sets or returns the vertical distance of the shadow from the shape.

• shadowOffsety=0 indicates that the shadow is right behind the shape.
• shadowOffsetY=20 indicates that the shadow starts 20 pixels below the shape’s top position.
• shadowOffsetY=-20 indicates that the shadow starts 20 pixels above the shape’s top position.

Tip: To adjust the horizontal distance of the shadow from the shape, use the shadowOffsetX property.

Property Values

Example

1 Draw a rectangle with a shadow placed 20 pixels below the rectangle’s top position

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.shadowBlur=10;
ctx.shadowOffsetY=20;
ctx.shadowColor="black";
ctx.fillStyle="red";
ctx.fillRect(20,20,100,80);

Method

createLinearGradient()

Definition and Usage

The createLinearGradient() method creates a linear gradient object.

The gradient can be used to fill rectangles, circles, lines, text, etc.

Tip: Use this object as the value to the strokeStyle or fillStyle properties.

Tip: Use the addColorStop() method to specify different colors, and where to position the colors in the gradient object.

Parameter Values

Example

查阅前文的fillStyle的Example 2、3、4，strokeStyle的Example 2。

createPattern()

Definition and Usage

The createPattern() method repeats the specified element in the specified direction.

The element can be an image, video, or another <canvas> element.

The repeated element can be used to draw/fill rectangles, circles, lines etc.

Parameter Values

Example

查阅前文的fillStyle的Example 5

当参数为repeat：

当参数为repeat-x：

当参数为repeat-y：

当参数为no-repeat：

createRadialGradient()

Definition and Usage

The createRadialGradient() method creates a radial/circular gradient object.

The gradient can be used to fill rectangles, circles, lines, text, etc.

Tip: Use this object as the value to the strokeStyle or fillStyle properties.

Tip: Use the addColorStop() method to specify different colors, and where to position the colors in the gradient object.

Parameter Values

Example

1 Draw a rectangle and fill with a radial/circular gradient:

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");

var grd=ctx.createRadialGradient(75,50,5,90,60,100);
grd.addColorStop(0,"red");
grd.addColorStop(1,"white");

// Fill with gradient
ctx.fillStyle=grd;
ctx.fillRect(10,10,150,100);

addColorStop()

Definition and Usage

The addColorStop() method specifies the colors and position in a gradient object.

The addColorStop() method is used together with createLinearGradient() or createRadialGradient().

Note: You can call the addColorStop() method multiple times to change a gradient. If you omit this method for gradient objects, the gradient will not be visible. You need to create at least one color stop to have a visible gradient.

Parameter Values

Example

1 Define a gradient with multiple addColorStop() methods

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");

var grd=ctx.createLinearGradient(0,0,170,0);
grd.addColorStop(0,"black");
grd.addColorStop(0.3,"magenta");
grd.addColorStop(0.5,"blue");
grd.addColorStop(0.6,"green");
grd.addColorStop(0.8,"yellow");
grd.addColorStop(1,"red");

ctx.fillStyle=grd;
ctx.fillRect(20,20,150,100);

Line Styles

Property

lineCap

Sets or returns the style of the end caps for a line

Definition and Usage

The lineCap property sets or returns the style of the end caps for a line.

Note: The value “round” and “square” make the lines slightly longer.

Property Values

Example

1 Draw a line with end caps

var c = document.getElementById("myCanvas");
var ctx = c.getContext("2d");

ctx.beginPath();
ctx.lineWidth = 10;
ctx.lineCap = "butt";
ctx.moveTo(20, 20);
ctx.lineTo(200, 20);
ctx.stroke();

ctx.beginPath();
ctx.lineCap = "round";
ctx.moveTo(20, 40);
ctx.lineTo(200, 40);
ctx.stroke();

ctx.beginPath();
ctx.lineCap = "square";
ctx.moveTo(20, 60);
ctx.lineTo(200, 60);
ctx.stroke();

lineJoin

Sets or returns the type of corner created, when two lines meet

Definition and Usage

The lineJoin property sets or returns the type of corner created, when two lines meet.

Note: The “miter” value is affected by the miterLimit property.

Property Values

bevel
英 [?bevl] 美 [?bevl]
n. 斜边;斜面;斜角规
v. 把（物体的方形边）改成斜面边

miter
英 [?ma?t??] 美 [?ma?t?r]
n. 主教法冠；斜接
v. 给主教等加冠；使斜接

Example

1 Create a different corner when the two lines meet

var c = document.getElementById("myCanvas");

var ctx = c.getContext("2d");
ctx.beginPath();
ctx.lineWidth = 10;
ctx.lineJoin = "round";//<---------------
ctx.moveTo(20, 20);
ctx.lineTo(100, 50);
ctx.lineTo(20, 100);
ctx.stroke();

ctx = c.getContext("2d");
ctx.beginPath();
ctx.lineWidth = 10;
ctx.lineJoin = "miter";//<--------------- Default. Creates a sharp corner
ctx.moveTo(20, 150);
ctx.lineTo(100, 180);
ctx.lineTo(20, 230);
ctx.stroke();


ctx = c.getContext("2d");
ctx.beginPath();
ctx.lineWidth = 10;
ctx.lineJoin = "bevel";//<--------------- 类似条形纸条斜折效果
ctx.moveTo(20, 280);
ctx.lineTo(100, 310);
ctx.lineTo(20, 360);
ctx.stroke();

lineWidth

Sets or returns the current line width

Definition and Usage

The lineWidth property sets or returns the current line width, in pixels.

Property Values

Example

参考上文lineJoin的例子

miterLimit

Sets or returns the maximum miter length

Definition and Usage

The miterLimit property sets or returns the maximum miter length.

The miter length is the distance between the inner corner and the outer corner where two lines meet.

Tip: The miterLimit property works only if the lineJoin attribute is “miter”.

The miter length grows bigger as the angle of the corner gets smaller.

To prevent the miter length from being too long, we can use the miterLimit property.

If the miter length exceeds the miterLimit value, the corner will be displayed as lineJoin type “bevel” （类似条形纸条斜折效果）(Fig 3):

Property Values

Example

1 Draw lines with the maximum miter length of 5

var c = document.getElementById("myCanvas");
var ctx = c.getContext("2d");
ctx.lineWidth = 10;
ctx.lineJoin = "miter";
ctx.miterLimit = 5;
ctx.moveTo(20, 20);
ctx.lineTo(50, 27);
ctx.lineTo(20, 34);
ctx.stroke();

/*
set the miterLimit to 4 (then, the miter length will exceed the miter limit), and when the lines meet it will be displayed as lineJoin="bevel".
*/

ctx = c.getContext("2d");
ctx.lineWidth = 10;
ctx.lineJoin = "miter";
ctx.miterLimit = 4;
ctx.moveTo(20, 50);
ctx.lineTo(50, 57);
ctx.lineTo(20, 64);
ctx.stroke();

Rectangles

Method

rect()

Creates a rectangle

Definition and Usage

The rect() method creates a rectangle.

Tip: Use the stroke()or the fill() method to actually draw the rectangle on the canvas.

Parameter Values

Example

1 Create three rectangles with the rect() method

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");

// Red rectangle
ctx.beginPath();
ctx.lineWidth="6";
ctx.strokeStyle="red";
ctx.rect(5,5,290,140);
ctx.stroke();

// Green rectangle
ctx.beginPath();
ctx.lineWidth="4";
ctx.strokeStyle="green";
ctx.rect(30,30,50,50);
ctx.stroke();

// Blue rectangle
ctx.beginPath();
ctx.lineWidth="10";
ctx.strokeStyle="blue";
ctx.rect(50,50,150,80);
ctx.stroke();

fillRect()

Draws a “filled” rectangle

Definition and Usage

The fillRect() method draws a “filled” rectangle. The default color of the fill is black.

Tip: Use the fillStyle property to set a color, gradient, or pattern used to fill the drawing.

Parameter Values

Example

1 Draw a filled 150*100 pixels rectangle

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.fillRect(20,20,150,100);

strokeRect()

Draws a rectangle (no fill)

Definition and Usage

The strokeRect() method draws a rectangle (no fill). The default color of the stroke is black.

Tip: Use the strokeStyle property to set a color, gradient, or pattern to style the stroke.

Parameter Values

Example

1 Draw a 150*100 pixels rectangle

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.strokeRect(20,20,150,100);

clearRect()

Clears the specified pixels within a given rectangle

Definition and Usage

The clearRect() method clears the specified pixels within a given rectangle.

Parameter Values

Example

1 Clear a rectangle within a given rectangle

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.fillStyle="red";
ctx.fillRect(0,0,300,150);
ctx.clearRect(20,20,100,50);

Paths

Method

fill()

Fills the current drawing (path)

Definition and Usage

The fill() method fills the current drawing (path). The default color is black.

Tip: Use the fillStyle property to fill with another color/gradient.

Note: If the path is not closed, the fill() method will add a line from the last point to the startpoint of the path to close the path (like closePath()), and then fill the path.

Example

1 Draw two 150*100 pixels rectangles. Fill one with a red color and the other with a blue color

var c = document.getElementById("myCanvas");
var ctx = c.getContext("2d");

ctx.beginPath();
ctx.rect(20, 20, 150, 100);
ctx.fillStyle = "red";
ctx.fill();

ctx.beginPath();
ctx.rect(40, 40, 150, 100);
ctx.fillStyle = "blue";
ctx.fill();

stroke()

Actually draws the path you have defined

stroke

英 [str??k] 美 [stro?k]

n. (打、击等的)一下;击球(动作);一击;划水动作;划桨动作;中风

vt. 轻抚(动物的毛皮);抚摩(物体表面或头发等);轻挪;轻触;轻拭

Definition and Usage

The stroke() method actually draws the path you have defined with all those moveTo() and lineTo() methods. The default color is black.

Tip: Use the strokeStyle property to draw with another color/gradient.

Example

1 Draw a path, shaped as the letter L - in a red color

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.beginPath();
ctx.moveTo(20,20);
ctx.lineTo(20,100);
ctx.lineTo(70,100);
ctx.strokeStyle="red";
ctx.stroke();

beginPath()

Begins a path, or resets the current path

Definition and Usage

The beginPath() method begins a path, or resets the current path.

Tip: Use moveTo(), lineTo(), quadricCurveTo(), bezierCurveTo(), arcTo(), and arc(), to create paths.

Tip: Use the stroke() method to actually draw the path on the canvas.

Example

1 Draw two paths on the canvas; one green and one purple

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");

ctx.beginPath();
ctx.lineWidth="5";
ctx.strokeStyle="green"; // Green path
ctx.moveTo(0,75);
ctx.lineTo(250,75);
ctx.stroke(); // Draw it

ctx.beginPath();
ctx.strokeStyle="purple"; // Purple path
ctx.moveTo(50,0);
ctx.lineTo(150,130);
ctx.stroke(); // Draw it

moveTo()

Moves the path to the specified point in the canvas, without creating a line

Definition and Usage

The moveTo() method moves the path to the specified point in the canvas, without creating a line.

Tip: Use the stroke() method to actually draw the path on the canvas.

Parameter Values

Example

1 Begin a path, move to position 0,0. Create a line to position 300,150

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.beginPath();
ctx.moveTo(0,0);
ctx.lineTo(300,150);
ctx.stroke();

closePath()

Creates a path from the current point back to the starting point

Definition and Usage

The closePath() method creates a path from the current point back to the starting point.

Tip: Use the stroke() method to actually draw the path on the canvas.

Tip: Use the fill() method to fill the drawing (black is default). Use the fillStyle property to fill with another color/gradient.

Example

1 Draw a path, shaped as the letter L, and then draw a line back to the starting point

var c = document.getElementById("myCanvas");
var ctx = c.getContext("2d");
ctx.beginPath();
ctx.moveTo(20, 20);
ctx.lineTo(20, 100);
ctx.lineTo(70, 100);
ctx.closePath();
ctx.stroke();

ctx.beginPath();
ctx.moveTo(20, 150);
ctx.lineTo(20, 230);
ctx.lineTo(70, 230);
//ctx.closePath();//<----------注释掉ctx.closePath()
ctx.stroke();

lineTo()

Adds a new point and creates a line to that point from the last specified point in the canvas

Definition and Usage

The lineTo() method adds a new point and creates a line TO that point FROM the last specified point in the canvas (this method does not draw the line).

Tip: Use the stroke() method to actually draw the path on the canvas.

Parameter Values

Example

参考上文closePath()的Example。

clip()

Clips剪出 a region of any shape and size from the original canvas

clip
英 [kl?p] 美 [kl?p]
n. 夹子;修剪;(金属或塑料的)回形针;首饰别针;剪短
v. 夹住;别住;被夹住;剪(掉);修剪;碰撞(某物的边缘或侧面)

Definition and Usage

The clip() method clips a region of any shape and size from the original canvas.

Tip: Once a region is clipped, all future drawing will be limited to the clipped region (no access to other regions on the canvas). You can however save the current canvas region using the save() method before using the clip() method, and restore it (with the restore() method) any time in the future.

Example

1 Clip of a rectangular region of 200*120 pixels from the canvas. Then, draw a red rectangle. Only the part of the red rectangle that is inside the clipped area is visible

<span>Without clip():</span>
<canvas id="myCanvas" width="300" height="150" style="border:1px solid #d3d3d3;">
Your browser does not support the HTML5 canvas tag.</canvas>

<script>

var c = document.getElementById("myCanvas");
var ctx = c.getContext("2d");
// Draw a rectangle
ctx.rect(50, 20, 200, 120);
ctx.stroke();
// Draw red rectangle
ctx.fillStyle = "red";
ctx.fillRect(0, 0, 150, 100);
</script>

<span>With clip():</span>
<canvas id="myCanvas2" width="300" height="150" style="border:1px solid #d3d3d3;">
Your browser does not support the HTML5 canvas tag.</canvas>

<script>
var c = document.getElementById("myCanvas2");
var ctx = c.getContext("2d");
// Clip a rectangular area
ctx.rect(50, 20, 200, 120);
ctx.stroke();
ctx.clip();
// Draw red rectangle after clip()
ctx.fillStyle = "red";
ctx.fillRect(0, 0, 150, 100);

</script>

quadraticCurveTo()

Creates a quadratic Bézier curve

quadratic
英 [kw??dr?t?k] 美 [kwɑ??dr?t?k]
adj. 平方的;二次方的

贝塞尔曲线（Bézier curve），又称贝兹曲线或贝济埃曲线，是应用于二维图形应用程序的数学曲线。一般的矢量图形软件通过它来精确画出曲线，贝兹曲线由线段与节点组成，节点是可拖动的支点，线段像可伸缩的皮筋，我们在绘图工具上看到的钢笔工具就是来做这种矢量曲线的。贝塞尔曲线是计算机图形学中相当重要的参数曲线，在一些比较成熟的位图软件中也有贝塞尔曲线工具，如PhotoShop等。百度百科

Definition and Usage

The quadraticCurveTo() method adds a point to the current path by using the specified control points that represent a quadratic Bézier curve.

A quadratic Bézier curve requires two points. The first point is a control point that is used in the quadratic Bézier calculation and the second point is the ending point for the curve. The starting point for the curve is the last point in the current path. If a path does not exist, use the beginPath() and moveTo() to define a starting point.

• Start point:

  • moveTo(20,20)

• Control point:

  • quadraticCurveTo(20,100,200,20)

• End point:

  • quadraticCurveTo(20,100,200,20)

Tip: Check out the bezierCurveTo() method. It has two control-points instead of one.

Parameter Values

Example

1 Draw a quadratic Bézier curve

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.beginPath();
ctx.moveTo(20,20);
ctx.quadraticCurveTo(20,100,200,20);
ctx.stroke();

bezierCurveTo()

Creates a cubic Bézier curve

cubic
英 [?kju?b?k] 美 [?kju?b?k]
adj. 立方体的;立方的;用立方单位度量(或表示)的;立方形的

Definition and Usage

The bezierCurveTo() method adds a point to the current path by using the specified control points that represent a cubic Bézier curve.

A cubic bezier curve requires three points. The first two points are control points that are used in the cubic Bézier calculation and the last point is the ending point for the curve. The starting point for the curve is the last point in the current path. If a path does not exist, use the beginPath() and moveTo() methods to define a starting point.

• Start point
  • moveTo(20,20)
• Control point 1
  • bezierCurveTo(20,100,200,100,200,20)
• Control point 2
  • bezierCurveTo(20,100,200,100,200,20)
• End point
  • bezierCurveTo(20,100,200,100,200,20)

Tip: Check out the quadraticCurveTo() method. It has one control point instead of two.

Parameter Values

Example

1 Draw a cubic Bézier curve

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.beginPath();
ctx.moveTo(20,20);
ctx.bezierCurveTo(20,100,200,100,200,20);
ctx.stroke();

arc()

Creates an arc/curve (used to create circles, or parts of circles)

arc
英 [ɑ?k] 美 [ɑ?rk]
n. 弧;弧形;电弧
vi. 作弧形运动;形成电弧

curve
英 [k??v] 美 [k??rv]
n. 曲线;弧线;曲面;弯曲;(投向击球员的)曲线球
v. (使)沿曲线运动;呈曲线形

Definition and Usage

The arc() method creates an arc/curve (used to create circles, or parts of circles).

Tip: To create a circle with arc(): Set start angle to 0 and end angle to 2*Math.PI.

Tip: Use the stroke() or the fill() method to actually draw the arc on the canvas.

• Center
  • arc(100,75,50,0 * Math.PI,1.5 * Math.PI)
• Start angle
  • arc(100,75,50,**0 * Math.PI ** ,1.5*Math.PI)
• End angle
  • arc(100,75,50,0 * Math.PI,1.5 * Math.PI)

Parameter Values

clockwise
英 [?kl?kwa?z] 美 [?klɑ?kwa?z]
adv./adj.顺时针方向的;顺时针方向(的)

counterclockwise
英 [?ka?nt??kl?kwa?z] 美 [?ka?nt?r?klɑ?kwa?z]
adj. 反时针方向的；逆时针方向的
adv. 逆时针方向地;自右向左地

Example

1 Create a circle

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.beginPath();
ctx.arc(100,75,50,0,2*Math.PI);
ctx.stroke();

arcTo()

Creates an arc/curve between two tangents

tangent
英 [?t?nd??nt] 美 [?t?nd??nt]
n. 切线;正切

Definition and Usage

The arcTo() method creates an arc/curve between two tangents on the canvas.

Tip: Use the stroke() method to actually draw the arc on the canvas.

Parameter Values

Example

1 Create an arc between two tangents on the canvas

var c = document.getElementById("myCanvas");
var ctx = c.getContext("2d");
ctx.beginPath();
ctx.moveTo(20, 20);               // Create a starting point
ctx.lineTo(100, 20);              // Create a horizontal line
ctx.arcTo(150, 20, 150, 70, 50);  // Create an arc
ctx.lineTo(150, 120);             // Continue with vertical line
ctx.stroke();                     // Draw it

isPointInPath()

Returns true if the specified point is in the current path, otherwise false

Definition and Usage

The isPointInPath() method returns true if the specified point is in the current path, otherwise false.

Parameter Values

Example

1 Draw a rectangle if the point 20,50 is in the current path

var c = document.getElementById("myCanvas");
var ctx = c.getContext("2d");
ctx.rect(20, 20, 150, 100);
if (ctx.isPointInPath(20, 50)) {
	ctx.stroke();
};

Transformations

Method

scale()

Scales the current drawing bigger or smaller

scale
英 [ske?l] 美 [ske?l]
n. 规模;(尤指与其他事物相比较时的)范围;程度;等级;级别;等级体系
vt. 攀登;到达…顶点;去鳞;刮除牙石

Definition and Usage

The scale() method scales the current drawing, bigger or smaller.

Note: If you scale a drawing, all future drawings will also be scaled. The positioning will also be scaled. If you scale(2,2); drawings will be positioned twice as far from the left and top of the canvas as you specify.

Parameter Values

Example

1 Draw a rectangle, scale to 200%, draw rectangle again, scale to 200%, draw rectangle again, scale to 200%, draw rectangle again

var c = document.getElementById("myCanvas");
var ctx = c.getContext("2d");
ctx.strokeStyle="black";
ctx.strokeRect(5, 5, 25, 15);

ctx.strokeStyle="red";
ctx.scale(2, 2);
ctx.strokeRect(5, 5, 25, 15);

ctx.strokeStyle="green";
ctx.scale(2, 2);
ctx.strokeRect(5, 5, 25, 15);

ctx.strokeStyle="blue";
ctx.scale(2, 2);
ctx.strokeRect(5, 5, 25, 15);

rotate()

Rotates the current drawing

Definition and Usage

The rotate() method rotates the current drawing.

Note: The rotation will only affect drawings made AFTER the rotation is done.

Parameter Values

Example

1 Rotate the rectangle 20 degrees

var c = document.getElementById("myCanvas");
var ctx = c.getContext("2d");
ctx.rotate(20 * Math.PI / 180);
ctx.fillRect(50, 20, 100, 50);

translate()

Remaps the (0,0) position on the canvas

Definition and Usage

The translate() method remaps the (0,0) position on the canvas.

Note: When you call a method such as fillRect() after translate(), the value is added to the x- and y-coordinate values.

Parameter Values

Note: You can specify one or both parameters.

Example

1 Draw a rectangle in position (10,10), set new (0,0) position to (70,70). Draw same rectangle again (notice that the rectangle now starts in position (80,80)

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.fillRect(10,10,100,50);
ctx.translate(70,70);
ctx.fillRect(10,10,100,50);

transform()

Replaces the current transformation matrix for the drawing

Definition and Usage

Each object on the canvas has a current transformation matrix.

The transform() method replaces the current transformation matrix. It multiplies the current transformation matrix with the matrix described by:

$?\begin{array}{ccc}a& c& e\\ b& d& f\\ 0& 0& 1\end{array}?$

In other words, the transform() method lets you scale, rotate, move, and skew the current context.

Note: The transformation will only affect drawings made after the transform() method is called.

Note: The transform() method behaves relatively to other transformations made by rotate(), scale(), translate(), or transform(). Example: If you already have set your drawing to scale by two, and the transform() method scales your drawings by two, your drawings will now scale by four.

Tip: Check out the setTransform() method, which does not behave relatively to other transformations.

Parameter Values

Example

1 Draw a rectangle, add a new transformation matrix with transform(), draw the rectangle again, add a new transformation matrix, then draw the rectangle again.

Notice that each time you call transform(), it builds on the previous transformation matrix

var c = document.getElementById("myCanvas");
var ctx = c.getContext("2d");

ctx.fillStyle = "yellow";
ctx.fillRect(0, 0, 250, 100)

ctx.transform(1, 0.5, -0.5, 1, 30, 10);
ctx.fillStyle = "red";
ctx.fillRect(0, 0, 250, 100);

ctx.transform(1, 0.5, -0.5, 1, 30, 10);
ctx.fillStyle = "blue";
ctx.fillRect(0, 0, 250, 100);

setTransform()

Resets the current transform to the identity matrix. Then runs transform()

Definition and Usage

Each object on the canvas has a current transformation matrix.

The setTransform() method resets the current transform to the identity matrix, and then runs transform() with the same arguments.

In other words, the setTransform() method lets you scale, rotate, move, and skew the current context.

Note: The transformation will only affect drawings made after the setTransform method is called.

Parameter Values

Example

1 Draw a rectangle, reset and create a new transformation matrix with setTransform(), draw the rectangle again, reset and create a new transformation matrix, then draw the rectangle again.

Notice that each time you call setTransform(), it resets the previous transformation matrix and then builds the new matrix, so in the example below, the red rectangle is not shown, because it is under the blue rectangle.

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");

ctx.fillStyle="yellow";
ctx.fillRect(0,0,250,100)

ctx.setTransform(1,0.5,-0.5,1,30,10);
ctx.fillStyle="red";
ctx.fillRect(0,0,250,100);

ctx.setTransform(1,0.5,-0.5,1,30,10);
ctx.fillStyle="blue";
ctx.fillRect(0,0,250,100);

PS.对比上文的transform()的Example对比理解。

Text

Property

font

Sets or returns the current font properties for text content

Definition and Usage

The font property sets or returns the current font properties for text content on the canvas.

The font property uses the same syntax as the CSS font property.

Property Values

Example

1 Write a 30px high text on the canvas, using the font “Arial”

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.font="30px Arial";
ctx.fillText("Hello World",10,50);

textAlign

Sets or returns the current alignment for text content

align
英 [??la?n] 美 [??la?n]
v. 排列;校准;排整齐;(尤指)使成一条直线;使一致

Definition and Usage

The textAlign property sets or returns the current alignment for text content, according to the anchor point.

Normally, the text will START in the position specified, however, if you set textAlign=“right” and place the text in position 150, it means that the text should END in position 150.

Tip: Use the fillText() or the strokeText() method to actually draw and position the text on the canvas.

Property Values

Example

1 Create a red line in position 150. Position 150 is the anchor point for all the text defined in the example below

Study the effect of each textAlign property value.

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");

// Create a red line in position 150
ctx.strokeStyle="red";
ctx.moveTo(150,20);
ctx.lineTo(150,170);
ctx.stroke();

ctx.font="15px Arial";

// Show the different textAlign values
ctx.textAlign="start";
ctx.fillText("textAlign=start",150,60);

ctx.textAlign="end";
ctx.fillText("textAlign=end",150,80);

ctx.textAlign="left";
ctx.fillText("textAlign=left",150,100);

ctx.textAlign="center";
ctx.fillText("textAlign=center",150,120);

ctx.textAlign="right";
ctx.fillText("textAlign=right",150,140);

textBaseline

Sets or returns the current text baseline used when drawing text

Definition and Usage

The textBaseline property sets or returns the current text baseline used when drawing text.

The illustration below demonstrates the various baselines supported by the textBaseline attribute:

Note: The fillText() and strokeText() methods will use the specified textBaseline value when positioning the text on the canvas.

Property Values

Example

1 Draw a red line at y=100, then place each word at y=100 with different textBaseline values

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");

//Draw a red line at y=100
ctx.strokeStyle="red";
ctx.moveTo(5,100);
ctx.lineTo(395,100);
ctx.stroke();

ctx.font="20px Arial"

//Place each word at y=100 with different textBaseline values
ctx.textBaseline="top";
ctx.fillText("Top",5,100);

ctx.textBaseline="bottom";
ctx.fillText("Bottom",50,100);

ctx.textBaseline="middle";
ctx.fillText("Middle",120,100);

ctx.textBaseline="alphabetic";
ctx.fillText("Alphabetic",190,100);

ctx.textBaseline="hanging";
ctx.fillText("Hanging",290,100);

Method

fillText()

Draws “filled” text on the canvas

Definition and Usage

The fillText() method draws filled text on the canvas. The default color of the text is black.

Tip: Use the font property to specify font and font size, and use the fillStyle property to render the text in another color/gradient.

Parameter Values

Example

1 Write “Hello world!” and “Big smile!” (with gradient) on the canvas, using fillText()

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");

ctx.font="20px Georgia";
ctx.fillText("Hello World!",10,50);

ctx.font="30px Verdana";

// Create gradient
var gradient=ctx.createLinearGradient(0,0,c.width,0);
gradient.addColorStop("0","magenta");
gradient.addColorStop("0.5","blue");
gradient.addColorStop("1.0","red");

// Fill with gradient
ctx.fillStyle=gradient;
ctx.fillText("Big smile!",10,90);

strokeText()

Draws text on the canvas (no fill)

Definition and Usage

The strokeText() method draws text (with no fill) on the canvas. The default color of the text is black.

Tip: Use the font property to specify font and font size, and use the strokeStyle property to render the text in another color/gradient.

Parameter Values

Example

1 Write “Hello world!” and “Big smile!” (with gradient) on the canvas, using strokeText()

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");

ctx.font="20px Georgia";
ctx.strokeText("Hello World!",10,50);

ctx.font="30px Verdana";
// Create gradient
var gradient=ctx.createLinearGradient(0,0,c.width,0);
gradient.addColorStop("0","magenta");
gradient.addColorStop("0.5","blue");
gradient.addColorStop("1.0","red");
// Fill with gradient
ctx.strokeStyle=gradient;
ctx.strokeText("Big smile!",10,90);

measureText()

Returns an object that contains the width of the specified text

Definition and Usage

The measureText() method returns an object that contains the width of the specified text, in pixels.

Tip: Use this method if you need to know the width of a text, before writing it on the canvas.

Parameter Values

Example

1 Check the width of the text, before writing it on the canvas

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
ctx.font="30px Arial";
var txt="Hello World"
ctx.fillText("width:" + ctx.measureText(txt).width,10,50)
ctx.fillText(txt,10,100);

Image Drawing

Method

drawImage()

Draws an image, canvas, or video onto the canvas

Definition and Usage

The drawImage() method draws an image, canvas, or video onto the canvas.

The drawImage() method can also draw parts of an image, and/or increase/reduce the image size.

Note: You cannot call the drawImage() method before the image has loaded. To ensure that the image has been loaded, you can call drawImage() from window.onload() or from document.getElementById(“imageID”).onload.

JavaScript Syntax

Position the image on the canvas:

Position the image on the canvas, and specify width and height of the image:

Clip the image and position the clipped part on the canvas:

Parameter Values

Example

1 Draw the image onto the canvas

window.onload = function() {
    var c=document.getElementById("myCanvas");
    var ctx=c.getContext("2d");
    var img=document.getElementById("scream");
    ctx.drawImage(img,10,10);
};

2 Position the image on the canvas, and specify width and height of the image

window.onload = function() {
    var c=document.getElementById("myCanvas");
    var ctx=c.getContext("2d");
    var img=document.getElementById("scream");
    ctx.drawImage(img,10,10,150,180);
};

3 Clip the image and position the clipped part on the canvas

window.onload = function() {
  var c=document.getElementById("myCanvas");
  var ctx=c.getContext("2d");
  var img=document.getElementById("scream");
  ctx.drawImage(img,90,130,50,60,10,10,50,60);
};

4 draws the current frame of the video every 20 millisecond

var v=document.getElementById("video1");
var c=document.getElementById("myCanvas");
var ctx=c.getContext('2d');
var i;

v.addEventListener('play',function() {i=window.setInterval(function() {ctx.drawImage(v,5,5,260,125)},20);},false);

v.addEventListener('pause',function() {window.clearInterval(i);},false);

v.addEventListener('ended',function() {clearInterval(i);},false);

Pixel Manipulation

Property

width

Returns the width of an ImageData object

Definition and Usage

The width property returns the width of an ImageData object, in pixels.

Tip: Look at createImageData(), getImageData(), and putImageData() to learn more about the ImageData object.

JavaScript Syntax

Example

略

height

Returns the height of an ImageData object

Definition and Usage

The height property returns the height of an ImageData object, in pixels.

Tip: Look at createImageData(), getImageData(), and putImageData() to learn more about the ImageData object.

JavaScript Syntax

Example

略

data

Returns an object that contains image data of a specified ImageData object

Definition and Usage

The data property returns an object that contains image data of the specified ImageData object.

For every pixel in an ImageData object there are four pieces of information, the RGBA values:

• R - The color red (from 0-255)
• G - The color green (from 0-255)
• B - The color blue (from 0-255)
• A - The alpha channel (from 0-255; 0 is transparent and 255 is fully visible)

The color/alpha information is held in an array, and is stored in the data property of the ImageData object.

Examples:

The syntax for making the first pixel in the ImageData object red:

imgData=ctx.createImageData(100,100);

imgData.data[0]=255;
imgData.data[1]=0;
imgData.data[2]=0;
imgData.data[3]=255;

The syntax for making the second pixel in the ImageData object green:

imgData=ctx.createImageData(100,100);

imgData.data[4]=0;
imgData.data[5]=255;
imgData.data[6]=0;
imgData.data[7]=255;

Tip: Look at createImageData(), getImageData(), and putImageData() to learn more about the ImageData object.

JavaScript Syntax

Example

略

Method

createImageData()

Creates a new, blank ImageData object

Definition and Usage

The createImageData() method creates a new, blank ImageData object. The new object’s pixel values are transparent black by default.

For every pixel in an ImageData object there are four pieces of information, the RGBA values:

• R - The color red (from 0-255)
• G - The color green (from 0-255)
• B - The color blue (from 0-255)
• A - The alpha channel (from 0-255; 0 is transparent and 255 is fully visible)

So, transparent black indicates: (0,0,0,0).

The color/alpha information is held in an array, and since the array contains 4 pieces of information for every pixel, the array’s size is 4 times the size of the ImageData object: widthheight4. (An easier way to find the size of the array, is to use ImageDataObject.data.length)

The array containing the color/alpha information is stored in the data property of the ImageData object.

Tip: After you have manipulated the color/alpha information in the array, you can copy the image data back onto the canvas with the putImageData() method.

Examples:

The syntax for making the first pixel in the ImageData object red:

imgData=ctx.createImageData(100,100);

imgData.data[0]=255;
imgData.data[1]=0;
imgData.data[2]=0;
imgData.data[3]=255;

The syntax for making the second pixel in the ImageData object green:

imgData=ctx.createImageData(100,100);

imgData.data[4]=0;
imgData.data[5]=255;
imgData.data[6]=0;
imgData.data[7]=255;

JavaScript Syntax

There are two versions of the createImageData() method:

1.This creates a new ImageData object with the specified dimensions (in pixels):

2.This creates a new ImageData object with the same dimensions as the object specified by anotherImageData (this does not copy the image data):

Parameter Values

Example

1 Create a 100*100 pixels ImageData object, and put it onto the canvas:

var c = document.getElementById("myCanvas");
var ctx = c.getContext("2d");
var imgData = ctx.createImageData(100, 100);

var i;
for (i = 0; i < imgData.data.length / 2; i += 4) {
    imgData.data[i+0] = 255;
    imgData.data[i+1] = 0;
    imgData.data[i+2] = 0;
    imgData.data[i+3] = 255;
}

for (i = imgData.data.length / 2; i < imgData.data.length; i += 4) {
    imgData.data[i+0] = 0;
    imgData.data[i+1] = 255;
    imgData.data[i+2] = 0;
    imgData.data[i+3] = 255;
}

ctx.putImageData(imgData, 10, 10);

getImageData()

Returns an ImageData object that copies the pixel data for the specified rectangle on a canvas

Definition and Usage

The getImageData() method returns an ImageData object that copies the pixel data for the specified rectangle on a canvas.

Note: The ImageData object is not a picture, it specifies a part (rectangle) on the canvas, and holds information of every pixel inside that rectangle.

For every pixel in an ImageData object there are four pieces of information, the RGBA values:

• R - The color red (from 0-255)

• G - The color green (from 0-255)

• B - The color blue (from 0-255)

• A - The alpha channel (from 0-255; 0 is transparent and 255 is fully visible)

The color/alpha information is held in an array, and is stored in the data property of the ImageData object.

Tip: After you have manipulated the color/alpha information in the array, you can copy the image data back onto the canvas with the putImageData() method.

Example:

The code for getting color/alpha information of the first pixel in the returned ImageData object:

red=imgData.data[0];
green=imgData.data[1];
blue=imgData.data[2];
alpha=imgData.data[3];

Tip: You can also use the getImageData() method to invert the color of every pixels of an image on the canvas.

Loop through all the pixels and change the color values using this formula:

red=255-old_red;
green=255-old_green;
blue=255-old_blue;

See below for a try it yourself example!

JavaScript Syntax

Parameter Values

Example

1 Use getImageData() to invert the color of every pixels of an image on the canvas

var c=document.getElementById("myCanvas");
var ctx=c.getContext("2d");
var img=document.getElementById("scream");
ctx.drawImage(img,0,0);
var imgData=ctx.getImageData(0,0,c.width,c.height);
// invert colors
for (var i=0;i<imgData.data.length;i+=4)
  {
  imgData.data[i]=255-imgData.data[i];
  imgData.data[i+1]=255-imgData.data[i+1];
  imgData.data[i+2]=255-imgData.data[i+2];
  imgData.data[i+3]=255;
  }
ctx.putImageData(imgData,0,0);

putImageData()

Puts the image data (from a specified ImageData object) back onto the canvas

Definition and Usage

The putImageData() method puts the image data (from a specified ImageData object) back onto the canvas.

Tip: Read about the getImageData() method that copies the pixel data for a specified rectangle on a canvas.

Tip: Read about the createImageData() method that creates a new, blank ImageData object.

JavaScript Syntax

Parameter Values

Example

1 putImageData() with optional parameter

<img id="scream" src="img_the_scream.jpg" alt="The Scream" width="220" height="277">
<canvas id="myCanvas" width="220" height="277" style="border:1px solid #d3d3d3;">
Your browser does not support the HTML5 canvas tag.</canvas>

<script>
document.getElementById("scream").onload = function() {
    var c = document.getElementById("myCanvas");
    var ctx = c.getContext("2d");
    var img = document.getElementById("scream");
    ctx.drawImage(img, 0, 0);
    var imgData = ctx.getImageData(0, 0, c.width, c.height);
    // invert colors
    var i;
    for (i = 0; i < imgData.data.length; i += 4) {
        imgData.data[i] = 255 - imgData.data[i];
        imgData.data[i+1] = 255 - imgData.data[i+1];
        imgData.data[i+2] = 255 - imgData.data[i+2];
        imgData.data[i+3] = 255;
    }
    ctx.putImageData(imgData, 0, 0, 0, 0, 110, 277);
};
</script>

Compositing

Property

globalAlpha

Sets or returns the current alpha or transparency value of the drawing

Definition and Usage

The globalAlpha property sets or returns the current alpha or transparency value of the drawing.

The globalAlpha property value must be a number between 0.0 (fully transparent) and 1.0 (no transparancy).

Property Values

Example

1 First, draw a red rectangle, then set transparency (globalAlpha) to 0.5, and then draw a blue and a green rectangle

var c = document.getElementById("myCanvas");
var ctx = c.getContext("2d");
ctx.fillStyle = "red";
ctx.fillRect(20, 20, 75, 50);

//Turn transparency on
ctx.globalAlpha = 0.1;

ctx.fillStyle = "blue";
ctx.fillRect(50, 50, 75, 50);

ctx.fillStyle = "green";
ctx.fillRect(80, 80, 75, 50);

globalCompositeOperation

Sets or returns how a new image are drawn onto an existing image

Definition and Usage

The globalCompositeOperation property sets or returns how a source (new) image are drawn onto a destination (existing) image.

source image = drawings you are about to place onto the canvas.

destination image = drawings that are already placed onto the canvas.

Property Values

Example

1 All the globalCompositeOperation property values

var gco = new Array();
gco.push("source-atop");
gco.push("source-in");
gco.push("source-out");
gco.push("source-over");
gco.push("destination-atop");
gco.push("destination-in");
gco.push("destination-out");
gco.push("destination-over");
gco.push("lighter");
gco.push("copy");
gco.push("xor");

var n;
for (n = 0; n < gco.length; n++) {
	document.write("<div id='p_" + n + "' style='float:left;'>" + gco[n] + ":<br>");
	var c = document.createElement("canvas");
	c.width = 120;
	c.height = 100;
	document.getElementById("p_" + n).appendChild(c);

    var ctx = c.getContext("2d");
	ctx.fillStyle = "blue";
	ctx.fillRect(10, 10, 50, 50);

    ctx.globalCompositeOperation = gco[n];

    ctx.beginPath();
	ctx.fillStyle = "red";
	ctx.arc(50, 50, 30, 0, 2 * Math.PI);
	ctx.fill();
	document.write("</div>");
}

Other

Method

save()

Definition and Usage

Push the current state on the state stack.

A drawing state is the set of the current settings of a CanvasRenderingContext2D object. It includes:

• the current style values (strokeStyle and fillStyle),
• globalAlpha and globalCompositeOperation,
• the line (lineWidth, lineCap, lineJoin, miterLimit),
• shadow (shadowOffsetX, shadowOffsetY, shadowBlur, shadowColor)
• text settings (font, textAlign, textBaseline),
• the current clipping region
• the current transformation matrix.

Each CanvasRenderingContext2D object maintains a stack of drawing states. And with save() and restore(), drawing states can be pushed onto this stack and recovered at a later point.

Note, that the drawing state does not include the current path or bitmaps. So save() and restore() do not save and restore entire canvas pictures, i.e. entire contents of the given context. For that, you should use ImageData objects and the getImageData() and putImageData() methods (see the chapter on pixel manipulation).

Example

1 save() and restore()

Suppose we draw 5 figures, each one a fillRect() rectangle with two lines of strokeText() text in it, like so:

As it is apparent from the picture, we use 3 different style settings for the 5 figures, defined as states:

• State A with a linear gradient fillStyle, running from top red to bottom green and yellow strokeStyle.

• State B with a radial gradient fillStyle, running from a orange center start to an outer green end circle and green strokeStyle.

• State C with dark gray fillStyle and light gray strokeStyle.

We could generate the previous canvas by following these steps:

1. declare State A and draw Figure 1 and 5
2. declare State B and draw Figure 2 and 4
3. declare State C and draw Figure 3

But since we want to demonstrate the use of save() and restore(), we create the Figures in their presented order:

1. set State A, draw Figure 1 and save State A on the state stack
2. set State B, draw Figure 2 and save State B on the state stack
3. set State C and draw Figure 3
4. overwrite State C by restoring State B from the stack and draw Figure 4
5. restore State A and draw Figure 5

The full source code that actually generated the canvas is this:

// Text style settings (these will be part of Start A, B, and C alike, because they do not change)
context.textAlign = 'center';
context.textBaseline = 'middle';
context.lineWidth = 2.0;
context.font = '25px Arial';
// Settings for State A
var verticalGrad = context.createLinearGradient (0,0,0,200);
verticalGrad.addColorStop (0,'red');
verticalGrad.addColorStop (1,'green');
context.fillStyle = verticalGrad;
context.strokeStyle = 'yellow';
// Draw Figure 1
context.fillRect (25,25,100,150);
context.strokeText ("Fig 1",75,50);
context.strokeText ("State A", 75,125);
// Save State A
context.save();

// Settings for State B
var radGrad = context.createRadialGradient (375,100,5, 375,100,200);
radGrad.addColorStop (0,'orange');
radGrad.addColorStop (1,'yellow');
context.fillStyle = radGrad;
context.strokeStyle = 'green';
// Draw Figure 2
context.fillRect (175,25,100,150);
context.strokeText ("Fig 2",225,50);
context.strokeText ("State B",225,125);
// Save State B
context.save();

// Settings for State C
context.fillStyle = '#888888';
context.strokeStyle = '#EEEEEE';
// Draw Figure 3
context.fillRect (325,25,100,150);
context.strokeText ("Fig 3",375,50);
context.strokeText ("State C",375,125);

// Pop State C and restore State B
context.restore();
// Draw Figure 4
context.fillRect (475,25,100,150);
context.strokeText ("Fig 4",525,50);
context.strokeText ("State B",525,125);

// Pop state B and restore state A
context.restore();
// Draw Figure 5
context.fillRect (625,25,100,150);
context.strokeText ("Fig 5",675,50);
context.strokeText ("State A",675,125);

restore()

Remove the top state from the state stack and thus restore the previous state that was pushed on the state stack.

Example

参考上文save()的Example

getContext()

HTMLCanvasElement.getContext (contextId)

returns the so-called context, i.e. an object that exposes an API for drawing on the canvas. Currently, only the CanvasRenderingContext2D object is supported, and for that the contextId is ‘2d’. The result of this call will be null if the given context ID is not supported.

This context, which will always be the 2D context in the sequel, is attached to the canvas and accessible by a call of canvas.getContext(‘2d’). This context is where all the action takes place. It provides the interface for all the drawings added to the given canvas and explaining the CanvasRenderingContext2D object below is thus the biggest part of this manual.

The [W3C] document announces that there will probably be a ‘3d’ context in the future, based on the OpenGL ES API.

Example

略

toDataURL()

Returns a data: URL for the image in the canvas. The first optional type argument controls the type of the image to be returned (e.g. PNG or JPEG). The default type is ‘image/png’ for PNG images. The other arguments are specific to the type and control the way that the image is generated.

Example

1 Convert the canvas into a data URL

Let us consider a very tiny canvas example, say a red 20x20 pixel rectangle

generated by the following code

<canvas id="DataUrlSample" width=20 height=20></canvas>
<script>
  var canvas = document.getElementById ('DataUrlSample');
  var context = canvas.getContext ('2d');
  context.fillStyle = 'red';
  context.fillRect (0, 0, 20, 20);
</script>

We can now convert the canvas into a PNG data URL by calling:

var dataUrl = canvas.toDataURL();

and dataUrl now holds this string:


If you copy this string and put it into the address field of your browser, you should see the picture of the red square.

We can also convert to a JPEG like so

var dataUrl = canvas.toDataURL('image/jpeg');

and then the result is this string:


You can copy all this and call it in your browser to get the little red square, again.

For a more convenient solution, we can attach these lines to the previous code:

canvas.onclick = function () {
  window.location = canvas.toDataURL('image/png');
};

If we then click on the canvas, the browser opens the data URL into the address field and thus shows the image. And then, the user can choose to save this image as a PNG file.
