[移动开发]Android~ 流式布局（适用搜索记录）**

##Android~ 流式布局（适用搜索记录）
感谢龙旋分享的文章，今天在做个记录
1.FlowLayout

public class FlowLayout extends ViewGroup {
    private int mHorizontalSpacing = dp2px(16); //每个item横向间距
    private int mVerticalSpacing = dp2px(8); //每个item横向间距

    private  List<List<View>> allLines ; // 记录所有的行，一行一行的存储
    private List<Integer> lineHeights = new ArrayList<>(); // 记录每一行的行高
    boolean isMeasuredOver = false;
    public FlowLayout(Context context) {
        super(context);
    }

    public FlowLayout(Context context, AttributeSet attrs) {
        super(context, attrs);
    }

    public FlowLayout(Context context, AttributeSet attrs, int defStyleAttr) {
        super(context, attrs, defStyleAttr);
    }

    @Override
    protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) {
        initMeasureParams();
        int childCount = getChildCount();
        int paddingLeft = getPaddingLeft();
        int paddingRight = getPaddingRight();
        int paddingTop = getPaddingTop();
        int paddingBottom = getPaddingBottom();
        //ViewGroup解析的宽度
        int selfWidth = MeasureSpec.getSize(widthMeasureSpec);
        int selfHeight = MeasureSpec.getSize(heightMeasureSpec); // ViewGroup解析的高度
        List<View> lineViews = new ArrayList<>(); //保存一行中的所有的view
        int lineWidthUsed = 0; //记录这行已经使用了多宽的size
        int lineHeight = 0; // 一行的行高

        int parentNeededWidth = 0;  // measure过程中，子View要求的父ViewGroup的宽
        int parentNeededHeight = 0; // measure过程中，子View要求的父ViewGroup的高

        for (int i = 0;i<childCount;i++){
            View childView = getChildAt(i);

            LayoutParams childLP = childView.getLayoutParams();
            int childWidthMesureSpec = getChildMeasureSpec(widthMeasureSpec,paddingLeft+paddingRight,childLP.width);
            int childHeightMesureSpec = getChildMeasureSpec(heightMeasureSpec,paddingBottom+paddingTop,childLP.height);

            childView.measure(childWidthMesureSpec,childHeightMesureSpec);
            //获取子view的宽高
            int childMesuredWidth = childView.getMeasuredWidth();
            int childMesuredHeight = childView.getMeasuredHeight();

            //通过宽度来判断是否需要换行，通过换行后的每行的行高来获取整个viewGroup的行高
            //如果宽度不够，则需换行
            if (childMesuredWidth + lineWidthUsed + mHorizontalSpacing > selfWidth){
                allLines.add(lineViews);
                lineHeights.add(lineHeight);

                //一旦换行，可以判断当前所需的宽高了
                parentNeededWidth = Math.max(parentNeededWidth,lineWidthUsed+ mHorizontalSpacing);
                parentNeededHeight = parentNeededHeight + lineHeight + mVerticalSpacing;

                lineViews = new ArrayList<>();
                lineWidthUsed = 0;
                lineHeight = 0;
            }
            // view 是分行layout的，所以要记录每一行有哪些view，这样可以方便layout布局
            lineViews.add(childView);
            lineWidthUsed = lineWidthUsed + childMesuredWidth + mHorizontalSpacing;
            lineHeight = Math.max(lineHeight,childMesuredHeight);

            //childview 最后一行
            if (i == childCount - 1){
                lineHeights.add(lineHeight);
                allLines.add(lineViews);
                parentNeededWidth = Math.max(parentNeededWidth,lineWidthUsed );
                parentNeededHeight += lineHeight ;
            }


            //根据子View的度量结果，来重新度量自己ViewGroup
            // 作为一个ViewGroup，它自己也是一个View,它的大小也需要根据它的父亲给它提供的宽高来度量
            int widthMode = MeasureSpec.getMode(widthMeasureSpec);
            int heightMode = MeasureSpec.getMode(heightMeasureSpec);

            int realWidth = (widthMode == MeasureSpec.EXACTLY)? selfWidth:parentNeededWidth;
            int realHeight = (heightMode == MeasureSpec.EXACTLY)?selfHeight:parentNeededHeight;

            setMeasuredDimension(realWidth,realHeight);
            isMeasuredOver = true;

        }
    }

    private void initMeasureParams() {
        allLines=new ArrayList<>();
        lineHeights=new ArrayList<>();
    }

    @Override
    protected void onLayout(boolean changed, int l, int t, int r, int b) {
        int lineCount = allLines.size();
        int curL = 0;
        int curT = 0;
        for (int i = 0;i<lineCount;i++){
            List<View> lineViews = allLines.get(i);
            int lineHeight = lineHeights.get(i);
            for (int j = 0;j<lineViews.size();j++){
                View view = lineViews.get(j);
                int left = curL;
                int top = curT;

                int bottom = top + view.getMeasuredHeight();
                int right = left + view.getMeasuredWidth();
                view.layout(left,top,right,bottom);
                curL = right + mHorizontalSpacing;
            }
            curL = 0;
            curT = curT + lineHeight + mVerticalSpacing;
        }
    }
    public static int dp2px(int dp) {
        return (int) TypedValue.applyDimension(TypedValue.COMPLEX_UNIT_DIP, dp, Resources.getSystem().getDisplayMetrics());
    }
}

2.布局

<?xml version="1.0" encoding="utf-8"?>
<ScrollView xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".FlowlayoutMainActivity">
    <LinearLayout
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:orientation="vertical">
        <TextView
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:layout_marginLeft="8dp"
            android:text="搜索历史"
            android:textColor="@android:color/black"
            android:textSize="18sp"/>
        <com.example.flowlayout.FlowLayout
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:layout_margin="8dp">
            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="抽油烟机通风口" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="帅哥洗衣机" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="吹风机全自动" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="百度" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="电动汽车可坐人" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="抽真空收纳袋" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="儿童滑板车" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="稳压器 电容" />


            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="猫咪棒" />


            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="奶粉1段" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="图书勋章日" />
        </com.example.flowlayout.FlowLayout>

        <TextView
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:layout_marginLeft="8dp"
            android:text="搜索发现"
            android:textColor="@android:color/black"
            android:textSize="18sp" />
        <com.example.flowlayout.FlowLayout
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:layout_margin="8dp">
            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="全场满200减99" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="奶粉2段" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="天猫双十一" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="伯爵茶" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="耐克1折秒杀" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="短尾猫" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="婴儿洗衣机" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="婴儿助手" />


            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="遥控飞机船" />


            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="热水袋" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="电动汽车" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="滑板车成年" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="抽油烟机" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="笔记本电脑" />

            <TextView
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:background="@drawable/shape_button_circular"
                android:text="电动手机" />
        </com.example.flowlayout.FlowLayout>
    </LinearLayout>

</ScrollView>

<?xml version="1.0" encoding="utf-8" ?>
<!--相当于做了一张圆角的图片,然后给button作为背景图片-->
<shape xmlns:android="http://schemas.android.com/apk/res/android"
    android:shape="rectangle">
    <solid android:color="#FFE7BA" />
    <padding android:bottom="8dp"
        android:left="8dp"
        android:right="8dp"
        android:top="8dp"/>
    <!--设置圆角-->
    <corners android:radius="25dp" />
</shape>
