[嵌入式]“蓝桥杯”第五届单片机省赛——模拟智能灌溉系统

? ? ? ? ?一、题目内容

? ? ? ? ?二、程序代码（含驱动代码）

注意：驱动函数需要改动一下，觉得好一键三连。

?主函数：

#include "stc15f2k60s2.h"
#include "intrins.h"
#include "ds1302.h"
#include "iic.h"
#define  control(x,y)  P0=x;P2=y;P2=0;

typedef unsigned char uchar;
typedef unsigned int uint;

uchar code dsp_code[]={0xc0,0xf9,0xa4,0xb0,0x99,0x92,0x82,0xf8,0x80,0x90,0xff,0xbf};
uchar dsp_Time[]={10,10,11,10,10,10,10,10};
uchar dsp_Set[]={11,11,10,10,10,10,10,10};

uchar L1,L2;
uchar buzzer,relay;                     //继电器 开   灌溉

uchar cnt,trg;
uchar count_key;                      //按键刷新率

uchar h,m,s;                             //8时30分

uchar shidu;
uchar count_adc;

uchar shidu_th=50;

uchar f_mode=0;                         //工作模式切换
bit flag_set;           //阈值调整界面标志
bit flag_beep=1;        //蜂鸣器功能标志

void Delay300ms()		//@11.0592MHz
{
	unsigned char i, j, k;

	_nop_();
	_nop_();
	i = 13;
	j = 156;
	k = 83;
	do
	{
		do
		{
			while (--k);
		} while (--j);
	} while (--i);
}

void Timer0Init(void)		//1毫秒@11.0592MHz
{
	AUXR |= 0x80;		//定时器时钟1T模式
	TMOD &= 0xF0;		//设置定时器模式
	TL0 = 0xCD;		//设置定时初值
	TH0 = 0xD4;		//设置定时初值
	TF0 = 0;		//清除TF0标志

	ET0=1;
	EA=1;
	TR0 = 1;		//定时器0开始计时
}
void Timer0_Service()  interrupt 1
{
	static uchar pos=0;

	uchar P0_Keeper=0,P2_Keeper=0;
	P0_Keeper=P0;P2_Keeper=P2;P2=0;

	control(0x00,0xc0);
	if(flag_set)
	{
		control(dsp_code[dsp_Set[pos]],0xe0);
	}
	else
	{
	control(dsp_code[dsp_Time[pos]],0xe0);
	}
	control(1 << pos ,0xc0);
	if(++pos == 8)
		pos=0;
	control(~(L1+L2*2),0x80);
	control(buzzer*64+relay*16,0xa0);

	++count_key;
	++count_adc;

	P0=P0_Keeper;P2=P2_Keeper;
}
/*==================================按键扫描函数==============================*/
void Scan_key()
{
	uchar readdat=P3^0xff;
	trg=readdat&(readdat^cnt);
	cnt=readdat;

	if(trg & 0x01)               //S7
	{
		if(!flag_set)
		{
			if(++f_mode == 2)
			{
				f_mode=0;
			}
		}
		flag_beep=1;

	}
	else if(trg & 0x02)              //S6
	{
		if(f_mode == 1)
		{
			flag_beep=~flag_beep;
		}
		else
		{
			flag_set=~flag_set;
			if(!flag_set)
			{
				EA=0;
				write_24c02(0x00,shidu_th);
				EA=1;
			}
		}
	}
	else if(trg & 0x04)              //S5
	{
		if(f_mode == 1)
		{
			relay=1;
		}
		else
		{
			if(flag_set)
			{
				++shidu_th;
			}
		}
	}

	else if(trg & 0x08)              //S4
	{
		if(f_mode == 1)
		{
			relay=0;
		}
		else
		{
			if(flag_set)
			{
				--shidu_th;
			}
		}
	}

}


void Display()
{

	dsp_Time[0]=h / 16;
	dsp_Time[1]=h % 16;

	dsp_Time[3]=m / 16;
	dsp_Time[4]=m % 16;

	dsp_Time[6]=shidu / 10;
	dsp_Time[7]=shidu % 10;

	dsp_Set[6]=shidu_th / 10;
	dsp_Set[7]=shidu_th % 10;

	if(f_mode == 1)
	{
		L2=1;L1=0;
		if(shidu < shidu_th)
		{
			if(flag_beep)
			{
				buzzer=1;
			}
		  else
		  {
			 buzzer=0;
		  }
	  }
		else
		{
			buzzer=0;
	  }
  }
	else
	{
		L1=1;L2=0;
		buzzer=0;
		if(shidu < shidu_th)
		{
			relay=1;
		}
		else
		{
			relay=0;
		}
	}
}
void Init_System()
{
	uchar i=0;

	control(0x00,0xa0);
	control(0xff,0x80);

	shidu_th=read_24c02(0x00);
	if(shidu_th > 99)
	{
		shidu_th=50;
	}

	for(i=0;i<5;i++)
	{
		shidu=(uchar)(read_adc(0x03)/2.57);
	}

	Set_Time(8,30,55);

	Timer0Init();
}

void main()
{
	Init_System();
	Delay300ms();
	while(1)
	{
		if(TH0 < 0xf0)
		{
			h=Read_Ds1302_Byte(0x85);
			m=Read_Ds1302_Byte(0x83);
			s=Read_Ds1302_Byte(0x81);
		}

    if(count_adc > 199)
		{
			count_adc=0;
			EA=0;

			shidu=(uchar)(read_adc(0x03)/2.57);

			EA=1;
		}
		Display();
		if(count_key > 9)
		{
			count_key=0;
			Scan_key();
		}
	}
}

ds1302.C驱动函数

#include <reg52.h>
#include <ds1302.h>
#include <intrins.h>

sbit SCK=P1^7;
sbit SDA=P2^3;
sbit RST = P1^3;   // DS1302复位

void Write_Ds1302(unsigned  char temp)
{
	unsigned char i;
	for (i=0;i<8;i++)
	{
		SCK=0;
		SDA=temp&0x01;
		temp>>=1;
		SCK=1;
	}
}

void Write_Ds1302_Byte( unsigned char address,unsigned char dat )
{
 	RST=0;	_nop_();
 	SCK=0;	_nop_();
 	RST=1; 	_nop_();
 	Write_Ds1302(address);
 	Write_Ds1302(dat);
 	RST=0;
}

unsigned char Read_Ds1302_Byte ( unsigned char address )
{
 	unsigned char i,temp=0x00;
 	RST=0;	_nop_();
 	SCK=0;	_nop_();
 	RST=1;	_nop_();
 	Write_Ds1302(address);
 	for (i=0;i<8;i++)
 	{
		SCK=0;
		temp>>=1;
 		if(SDA)
 		temp|=0x80;
 		SCK=1;
	}
 	RST=0;	_nop_();
 	SCK=0;	_nop_();
	SCK=1;	_nop_();
	SDA=0;	_nop_();
	SDA=1;	_nop_();
	return (temp);
}

/*=========================================================================*/
void Set_Time(char h, char m,char s)
{
	Write_Ds1302_Byte(0x8e,0x00);

	Write_Ds1302_Byte(0x84,(h/10)*16+h%10);
	Write_Ds1302_Byte(0x82,(m/10)*16+m%10);
	Write_Ds1302_Byte(0x80,(s/10)*16+m%10);

	Write_Ds1302_Byte(0x8e,0x80);
}

ds1302.h驱动函数

#ifndef __DS1302_H
#define __DS1302_H

void Write_Ds1302(unsigned char temp);
void Write_Ds1302_Byte( unsigned char address,unsigned char dat );
unsigned char Read_Ds1302_Byte( unsigned char address );

void Set_Time(char h, char m,char s);

#endif

iic.c驱动函数

#include "reg52.h"
#include "iic.h"
#include "intrins.h"

#define DELAY_TIME 5

#define SlaveAddrW 0xA0
#define SlaveAddrR 0xA1

//总线引脚定义
sbit SDA = P2^1;  /* 数据线 */
sbit SCL = P2^0;  /* 时钟线 */

void IIC_Delay(unsigned char i)
{
    do{_nop_();}
    while(i--);
}
//总线启动条件
void IIC_Start(void)
{
    SDA = 1;
    SCL = 1;
    IIC_Delay(DELAY_TIME);
    SDA = 0;
    IIC_Delay(DELAY_TIME);
    SCL = 0;
}

//总线停止条件
void IIC_Stop(void)
{
    SDA = 0;
    SCL = 1;
    IIC_Delay(DELAY_TIME);
    SDA = 1;
    IIC_Delay(DELAY_TIME);
}

//发送应答
//void IIC_SendAck(bit ackbit)
//{
//    SCL = 0;
//    SDA = ackbit;  					// 0：应答，1：非应答
//    IIC_Delay(DELAY_TIME);
//    SCL = 1;
//    IIC_Delay(DELAY_TIME);
//    SCL = 0;
//    SDA = 1;
//    IIC_Delay(DELAY_TIME);
//}

//等待应答
bit IIC_WaitAck(void)
{
    bit ackbit;

    SCL  = 1;
    IIC_Delay(DELAY_TIME);
    ackbit = SDA;
    SCL = 0;
    IIC_Delay(DELAY_TIME);
    return ackbit;
}

//通过I2C总线发送数据
void IIC_SendByte(unsigned char byt)
{
    unsigned char i;

    for(i=0; i<8; i++)
    {
        SCL  = 0;
        IIC_Delay(DELAY_TIME);
        if(byt & 0x80) SDA  = 1;
        else SDA  = 0;
        IIC_Delay(DELAY_TIME);
        SCL = 1;
        byt <<= 1;
        IIC_Delay(DELAY_TIME);
    }
    SCL  = 0;

		IIC_WaitAck();

}

//从I2C总线上接收数据
unsigned char IIC_RecByte(void)
{
    unsigned char i, da;
    for(i=0; i<8; i++)
    {
    	SCL = 1;
	IIC_Delay(DELAY_TIME);
	da <<= 1;
	if(SDA) da |= 1;
	SCL = 0;
	IIC_Delay(DELAY_TIME);
    }

		IIC_WaitAck();

    return da;
}

/*===================================24c02==============================*/
void write_24c02(unsigned char add,unsigned char dat)
{
	IIC_Start();
	IIC_SendByte(0xa0);
	IIC_SendByte(add);
	IIC_SendByte(dat);
	IIC_Stop();
}
unsigned char read_24c02(unsigned char add)
{
	unsigned char dat;

	IIC_Start();
	IIC_SendByte(0xa0);
	IIC_SendByte(add);

	IIC_Start();
	IIC_SendByte(0xa1);
	dat=IIC_RecByte();
	IIC_Stop();

	return dat;

}
/*=============================PCF8591读取rb2的值================================*/
unsigned char read_adc(unsigned char add)
{
	unsigned char dat;

	IIC_Start();
	IIC_SendByte(0x90);
	IIC_SendByte(add);

	IIC_Start();
	IIC_SendByte(0x91);
	dat=IIC_RecByte();
	IIC_Stop();

	return dat;
}

iic.h驱动函数

#ifndef _IIC_H
#define _IIC_H

void IIC_Start(void);
void IIC_Stop(void);
bit IIC_WaitAck(void);
//void IIC_SendAck(bit ackbit);
void IIC_SendByte(unsigned char byt);
unsigned char IIC_RecByte(void);

unsigned char read_adc(unsigned char add);

void write_24c02(unsigned char add,unsigned char dat);
unsigned char read_24c02(unsigned char add);

#endif
