[嵌入式]ESP32——UPL 唤醒

UPL 唤醒

ULP协处理器是RTC外设电源域的一部分，它运行存储在RTC慢速存储器中的程序。ULP协处理器可以在芯片处于休眠模式时运行，可用于轮询传感器、监控ADC或触摸传感器值，以及在检测到特定事件时唤醒芯片。如果请求此唤醒模式，则 RTC 慢速内存将在睡眠期间打开电源。在ULP协处理器开始运行程序之前，RTC外设将自动通电;一旦程序停止运行，RTC外设将再次自动断电。

esp_sleep_enable_ulp_wakeup()该函数用于启用此唤醒源。

您可以使用以下命令上传 ULP 程序：

void init_ulp_program() {
    const ulp_insn_t program[] = {
            // initiate wakeup of the SoC启动SoC唤醒
            I_WAKE(),
            // stop the ULP program停止ULP程序
            I_HALT()
    };

    size_t load_addr = 0;
    size_t size = sizeof(program)/sizeof(ulp_insn_t);
    ulp_process_macros_and_load(load_addr, program, &size);

    ulp_run(0);
}

设置 ULP 唤醒周期的命令是：

esp_err_t ulp_set_wakeup_period(size_t period_index, uint32_t period_us);

参数：
报警周期设置（0 – 4）
唤醒周期的索引，以μs为单位period_index ``period_us a

成功

回报如果 period_index超出范围ESP_OK ESP_ERR_INVALID_ARG

用于唤醒 esp32 的 ULP 命令包括：

 // initiate wakeup of the SoC
    I_WAKE(),
// stop the ULP program
    I_HALT()

这是完整的草图：

/*
 *  ESP32
 *  DEEP Sleep and ULP wake up
 *  by Mischianti Renzo <https://www.mischianti.org>
 *
 *  https://www.mischianti.org/2021/03/23/esp32-practical-power-saving-preserve-gpio-status-external-and-ulp-wake-up-5/
 *
 */

#include "esp32/ulp.h"
#include "soc/rtc_cntl_reg.h"
#include "driver/rtc_io.h"

void init_ulp_program();

RTC_DATA_ATTR int bootCount = 0;

/*
Method to print the reason by which ESP32
has been awaken from sleep方法打印ESP32从睡眠中被唤醒的原因
*/
void print_wakeup_reason(){
  esp_sleep_wakeup_cause_t wakeup_reason;

  wakeup_reason = esp_sleep_get_wakeup_cause();

  switch(wakeup_reason)
  {
    case ESP_SLEEP_WAKEUP_EXT0 : Serial2.println("Wakeup caused by external signal using RTC_IO"); break;
    case ESP_SLEEP_WAKEUP_EXT1 : Serial2.println("Wakeup caused by external signal using RTC_CNTL"); break;
    case ESP_SLEEP_WAKEUP_TIMER : Serial2.println("Wakeup caused by timer"); break;
    case ESP_SLEEP_WAKEUP_TOUCHPAD : Serial2.println("Wakeup caused by touchpad"); break;
    case ESP_SLEEP_WAKEUP_ULP : Serial2.println("Wakeup caused by ULP program"); break;
    default : Serial2.printf("Wakeup was not caused by deep sleep: %d\n",wakeup_reason); break;
  }
}

void setup() {
    Serial2.begin(115200);
    while( !Serial ){}

    Serial2.println("Init");

    //Increment boot number and print it every reboot
    ++bootCount;
    Serial2.println("Boot number: " + String(bootCount));

    //Print the wakeup reason for ESP32
    print_wakeup_reason();

    esp_sleep_wakeup_cause_t cause = esp_sleep_get_wakeup_cause();
    if (cause != ESP_SLEEP_WAKEUP_ULP) {
        Serial2.println("Initializing ULP");
        init_ulp_program();
        /* Set ULP wake up period to 5s */
        /*设置ULP唤醒周期为5s */
        ulp_set_wakeup_period(0, 5 * 1000 * 1000);
    }

    Serial2.println("Entering deep sleep\n");
    ESP_ERROR_CHECK( esp_sleep_enable_ulp_wakeup() );

    esp_deep_sleep_start();
}

void loop(){
}

void init_ulp_program() {
    const ulp_insn_t program[] = {
            // initiate wakeup of the SoC
            I_WAKE(),
            // stop the ULP program
            I_HALT()
    };

    size_t load_addr = 0;
    size_t size = sizeof(program)/sizeof(ulp_insn_t);
    ulp_process_macros_and_load(load_addr, program, &size);

    ulp_run(0);
}

串行2 输出为

Init
Boot number: 1
Wakeup was not caused by deep sleep: 0
Entering deep sleep

Init
Boot number: 2
Wakeup caused by ULP program
ULP wakeup
Entering deep sleep

Init
Boot number: 3
Wakeup caused by ULP program
ULP wakeup
Entering deep sleep

结束
